HPE S1G79-61001 Aruba Networking AP-754 (RW) Tri Radio 4x4 Wi-Fi 7 External Antennas TAA Campus Access Point
Part Number:
S1G79-61001
Got a Big Order or a Quick Question?
Let’s Connect—We Make Tech Buying Effortless.
Let’s Connect—We Make Tech Buying Effortless.
For Govt Institution credit terms or bulk order - Submit your detail below
Note: All heavy items above 20KG will be charged shipping
cost as per actual. Please contact us for a shipping quote before placing
order.
We accept Purchase Orders from Health & Educational
sector and all Government institutions including Councils.
Product Overview Bluetooth Sig
Ethernet Alliance (poe, Pd Device, Class 6)
Ul2043 Plenum Rating
Wi-fi Alliance (wfa)
Wi-fi Certified A, B, G, N, Ac, 6, 7
Wpa, Wpa2 And Wpa3- Enterprise With Cnsa Option, Personal (sae), Enhanced Open (owe)
Wmm, Wmm-ps, W-fi Agile Multiband
Regulatory
Fcc/ised
Ce Marked
Red Directive 2014/53/eu
Emc Directive 2014/30/eu
Low Voltage Directive 2014/35/eu
Ul/iec/en 60950
Iec/en 62368-1
En 60601-1-1
En60601-1-2
Wi-fi Antenna Two Sets Of Four (female) Rp-sma Connectors For External Antennas (a0 Through A3 Corresponding With Radio Chains 0 Through 3 For The 2.4 Ghz And 5 Ghz Radios, And B0 Through B3 Corresponding With Radio Chains 0 Through 3 For The 6 Ghz Radio). Worst-case Internal Loss Between Radio Interface And External Antenna Connectors: 1.1db In 2.4 Ghz, 1.8db In 5 Ghz, And 2.8db In 6 Ghz.
Connectivity, Standard 802.11be
Ports
E0, E1: Two Ethernet Wired Network Ports (rj-45)
U0, U1: Two Usb 2.0 Host Interface (type A Connector)
Serial Console Interface (proprietary, Micro-b Usb Physical Jack)
Kensington Security Slot
Power Consumption
Maximum (worst Case) Power Consumption (without/with Usb Devices Attached):
- Dc Powered: 35w/46w
- Poe Powered: 40w/51w
This Assumes That Up To 10w Is Supplied To The Attached Usb Device(s)
- Maximum (worst-case) Power Consumption In Idle Mode: 14w/25w (dc) Or 12w/23w (poe)
- Maximum (worst-case) Power Consumption In Deep-sleep Mode: 2.4w (dc) Or 3.5w (poe)
Radio Coverage Ap Type: Indoor, Tri Radio, 2.4 Ghz, 5 Ghz And 6 Ghz (concurrent) 802.11be 4x4 Mimo
Condition: New Factory Sealed.
Availability: Call.
Our Warranty: 90 Days.
HPE S1G79-61001 Aruba Networking Ap-754 (rw) Tri Radio 4x4 Wi-fi 7 External Antennas Taa Campus Access Point
Specifications
Certifications
Regulatory
Wi-fi Antenna Two Sets Of Four (female) Rp-sma Connectors For External Antennas (a0 Through A3 Corresponding With Radio Chains 0 Through 3 For The 2.4 Ghz And 5 Ghz Radios, And B0 Through B3 Corresponding With Radio Chains 0 Through 3 For The 6 Ghz Radio). Worst-case Internal Loss Between Radio Interface And External Antenna Connectors: 1.1db In 2.4 Ghz, 1.8db In 5 Ghz, And 2.8db In 6 Ghz.
Connectivity, Standard 802.11be
Ports
Power Consumption
- Dc Powered: 35w/46w
- Poe Powered: 40w/51w
- Maximum (worst-case) Power Consumption In Idle Mode: 14w/25w (dc) Or 12w/23w (poe)
- Maximum (worst-case) Power Consumption In Deep-sleep Mode: 2.4w (dc) Or 3.5w (poe)
Radio Coverage Ap Type: Indoor, Tri Radio, 2.4 Ghz, 5 Ghz And 6 Ghz (concurrent) 802.11be 4x4 Mimo
Condition: New Factory Sealed.
Availability: Call.
Our Warranty: 90 Days.
| Capacity | WIRELESS 18.7GBPS |
|---|---|
| Condition | New Factory Sealed |
| Manufacturer | HPE |
