HPE S0B85-61001 Aruba Networking 9106 2x SFP+ 2x Combo 2x PoE Hybrid Gateway
Part Number:
S0B85-61001
Got a Big Order or a Quick Question?
Let’s Connect—We Make Tech Buying Effortless.
Let’s Connect—We Make Tech Buying Effortless.
For Govt Institution credit terms or bulk order - Submit your detail below
Note: All heavy items above 20KG will be charged shipping
cost as per actual. Please contact us for a shipping quote before placing
order.
We accept Purchase Orders from Health & Educational
sector and all Government institutions including Councils.
Product Overview Versatile, Scalable Platform For Cloud-based Wireless Gateway, Sd-branch Device, Or Vpn Concentrator Use Cases
Scalable Cloud-native Aos 10 Architecture Provides Connectivity For Up To 4k Aps And 10k Clients
Streamlined Cloud-based Management And Control With HPE Aruba Networking Central
Dynamic Segmentation For Automated Role-based Policy Enforcement Across Users, Devices, And Iot
Always-on High Availability With Live Upgrades, Clustering, And N+1 Or Nxn Redundancy
High-speed Wired Connectivity With 10gbe Fiber Ports For Up To 20gbps Throughput
Zero-touch Provisioning Simplifies Deployment At Branch Sites
Technical Specifications
Performance And Capacity - 10
Firewall Throughput (gbps) - 10
Encrypted Throughput Gre (gbps) - 10
Encrypted Throughput Aes-cbc-128 (gbps) - 10
Encrypted Throughput Aes-cbc-256 (gbps) - 10
Encrypted Throughput Aes-gcm-128 (gbps) - 10
Encrypted Throughput Aes-gcm-256 (gbps) - 10
Cluster Size - 6
Maximum Clients (user Mac)- 8k
Maximum Clients Per Cluster - 32k
Max Devices (aps) Per Gateway - 2k
Max Devices (aps) Per Cluster - 4k
Maximum Data Path/ Firewall Sessions - 2m
Concurrent Ipsec Tunnels - 16k
Total Tunnels - 20k
Max Dhcp Clients - 16k
Maximum Bridge Table - 256k
Max Ipv4 Static Routes - 2k
Ipv6 Neighbors - 32k
Maximum Routes - 32k
Access Lists - 2678
Configurable Bandwidth Contracts - 1k
Interfaces And Indicators
Form Factor - Desktop
Interface
- 2x Spf+
- 2x Combo (sfp/1g Copper)
- 2x 1 Gbe
Poe Budget- 60w
Out Of Band Management Port - 1x Rj45
Console Port- Usb-c, Rj45
Usb 3.0 Type-a - 1
Lcd Display -
Power Led - Yes
status Led - Yes
Gateway Led - Yes
Peered Led (reserved For Future Use) - Tbd
Expansion Slot (reserved For Future Use) -
Power Supply Slots -
Fan Trays -
Physical
Dimensions - (h X W X D) 43.7 Mm (h) X 294.8 Mm (w) X 201.05mm (d)
Weight - 2.305 Kg
Mtbf (hours At 25c With Fans And Psu)- 236076
Environmentals
Operating Temperature- 0 °c To 40 °c (32 °f To 104 °f)
Storage Temperature –40 °c To 70 °c (–40 °f To 158 °f)
Humidity/storage Humidity - 10% To 90% (rh)/10% To 95% (rh), Non-condensing
Operating Altitude - 10,000 Feet
Acoustic Noise - 54.6 Dba
Maximum Heat Dissipation (btu/hour) - 290
Maximum Power Consumption - 150w
Power Source - 150w
Power Supply Certifications
Input Voltage Range - 100 Vac To 240 Vac
Output Voltage - 54v
Input Frequency - 50 To 60 Hz
Ac Line Input Current (steady State) - 2.5a
Operating Temperature - 0 To 40c
Cooling -
Weight - 0.5 +/- 0.02 Kg
Condition: New Factory Sealed.
Availability: Call.
Our Warranty: 90 Days.
HPE S0B85-61001 Aruba Networking 9106 2x Sfp+ 2x Combo 2x Poe Hybrid Gateway
Overview
Scalable, Secure And Intelligent Cloud-based Edge Appliance
The HPE Aruba Networking 9100 Series Hybrid Gateways Is A Cloud-optimized Edge Appliance Designed To Extend Enterprise Services Securely And Seamlessly To Large Branch And Small Campus Networks. This Purpose-built High-performance Edge Appliance Delivers Wi-fi Roaming, 24x7 Reliability, And Always-on Connectivity – Even During Upgrades. Intelligent Automation, Ai Insights, And Unified Infrastructure Management, Provided By HPE Aruba Networking Operating System 10 And HPE Aruba Networking Central, Help Drive Efficient It Operations.
The HPE Aruba Networking 9100 Series Hybrid Gateway Provides Advanced Wireless Capabilities, Intelligent Routing With Both Wireless And Wired Tunnel Orchestration, And Strengthens Security With Automated And Unified Role-based Policy Enforcement For Users And Iot Across Lan, Wan And Sd-wan. This Cloud-based Edge Appliance Takes Advantage Of Aos 10 Distributed Software Architecture And HPE Aruba Networking Central For Greater Scalability, Security, And Ai-powered Optimization. Importantly, It Adds The Versatility For Network Services To Be Provided On-premises, Allowing The HPE Aruba Networking 9100 Series Hybrid Gateways To Bring Needed Scalability To Campus Wireless Gateway Use Cases Or To Optimize Local Routing And Services At Branch Networks.
Ideal For Large Branch Deployments And Small Campus Networks, The HPE Aruba Networking 9100 Series Hybrid Gateway Is Cloud-managed Which Reduces On-site It Requirements. It Can Operate In Several Modes: As An Sd-branch Gateway For Tunnel And Route Orchestration, Security, And Wan Management, As A Powerful Cloud-based Wireless Gateway, Or Vpn Concentrator (vpnc) For Remote Network And Client Vpn Connectivity.
Key Features
Technical Specifications
Interfaces And Indicators
- 2x Spf+
- 2x Combo (sfp/1g Copper)
- 2x 1 Gbe
Physical
Environmentals
Power Supply Certifications
Condition: New Factory Sealed.
Availability: Call.
Our Warranty: 90 Days.
| Capacity | Gateway |
|---|---|
| Condition | New Factory Sealed |
| Manufacturer | HPE |
