HPE R8S91A Aruba CX 6300M 12p CL8 PoE 36p CL6 PoE SR 1G/2.5G/5G 2p 50G 2p 10G Switch
Part Number:
R8S91A
Got a Big Order or a Quick Question?
Let’s Connect—We Make Tech Buying Effortless.
Let’s Connect—We Make Tech Buying Effortless.
For Govt Institution credit terms or bulk order - Submit your detail below
Note: All heavy items above 20KG will be charged shipping
cost as per actual. Please contact us for a shipping quote before placing
order.
We accept Purchase Orders from Health & Educational
sector and all Government institutions including Councils.
Product Overview Device Type : Switch - 48 Ports - L3 - Managed - Stackable
Enclosure Type : Rack-mountable 1u
Subtype : Gigabit Ethernet
Ports : 48 X 100/1000/2.5g/5g (poe++) + 2 X 10 Gigabit / 25 Gigabit / 50 Gigabit Sfp56 (uplink / Stacking) + 2 X 1 Gigabit / 10 Gigabit Sfp+
Power Over Ethernet (poe) : Poe++
Performance : Switching Capacity: 496 Gbps ¦ Throughput: 369 Mpps ¦ Latency (1 Gbps): 2.28 Μs ¦ Latency (10 Gbps): 1.46 Μs ¦ Latency (25 Gbps): 1.9 Μs ¦ Latency (50 Gbps): 3.49 Μs ¦ Stacking Bandwidth: 200 Gbps
Capacity : Switched Virtual Interfaces (svis): 1024 ¦ Ipv4 Host Table Capacity: 49152 ¦ Ipv6 Host Table Capacity: 49152 ¦ Ipv4 Routes (unicast): 61000 ¦ Ipv6 Routes (unicast): 61000 ¦ Ipv4 Routes (multicast): 8192 ¦ Ipv6 Routes (multicast): 8192 ¦ Igmp Groups: 8192 ¦ Mld Groups: 8192 ¦ Ipv4 Acl Entries (ingress): 20480 ¦ Ipv6 Acl Entries (ingress): 5120 ¦ Mac Acl Entries (ingress): 20480 ¦ Ipv4 Acl Entries (egress): 8192 ¦ Ipv6 Acl Entries (egress): 2048 ¦ Mac Acl Entries (egress): 8192
Mac Address Table Size : 32768 Entries
Jumbo Frame Support : 9198 Bytes
Routing Protocol : Ospf, Bgp-4, Bgp, Igmpv2, Igmp, Vrrp, Ospfv2, Pim-sm, Pim-dm, Igmpv3, Gre, Ospfv3, Msdp, Ecmp, Policy-based Routing (pbr), Mld, Bidirectional Forwarding Detection (bfd), Mstp, Rstp, Stp
Remote Management Protocol : Snmp, Rmon, Telnet, Snmp 3, Snmp 2c, Tftp, Ssh, Cli, Sftp
Encryption Algorithm : Fips 140-2
Authentication Method : Secure Shell (ssh), Radius, Tacacs+, Secure Shell V.2 (ssh2)
Features : Vlan Support, Auto-uplink (auto Mdi/mdi-x), Syslog Support, Ipv6 Support, High Availability, Sflow, Stp Support, Rstp Support, Pvst, Mstp Support, Acl Support, Qos, Dwrr, Lldp Support, Fan Tray, Mib, Dhcp Protection, Dual Firmware Images, Mvrp, Packet Storm Protection, Cos, Broadcast Storm Protection, Tos, Bpdu, Vxlan, Multicast Storm Protection, Ntp, Ra Guard, Ztp, Pim, Vlan Tagging, Rstp, Ipv4 And Ipv6 Dual Stack, Ip Multicast, Bsr Mechanism, Aruba Vsf, Dynamic Ipv6 Lockdown, Nd Snooping, Unicast Storm Protection, Microsoft Nlb
Compliant Standards : Ieee 802.1d, Ieee 802.1q, Ieee 802.1p, Ieee 802.3af, Ieee 802.3ad (lacp), Ieee 802.1w, Ieee 802.1x, Ieee 802.1s, Ieee 802.1t, Ieee 802.1v, Ieee 802.1ab (lldp), Ieee 802.1ak, Ieee 802.1ax, Ieee 802.3bt
Processor : 1 X Arm: 1.8 Ghz
Ram : 8 Gb Ddr4 Sdram
Flash Memory : 32 Gb
Expansion / Connectivity :
Interfaces :
48 X 10/100/1000 Base-t Rj-45
4 X 1gbit/10gbit/25gbit/50gbit Sfp56
1 X Usb-c
1 X Management
1 X Usb Type A
Power :
Power Device : Internal Power Supply - Hot-plug
Installed Qty : 1
Max Supported Qty : 2
Power Redundancy : Optional
Power Redundancy Scheme : 1+1 (with Optional Power Supply)
Power Provided : 75 Watt
Voltage Required : (50/60 Hz)
Condition : New Factory Sealed
Availability : In Stock
Our Warranty : 90 Days
HPE R8S91A Aruba 6300m - Switch - L3 - Managed - 48 X 100/1000/2.5g/5g (poe++) + 2 X 10 Gigabit / 25 Gigabit / 50 Gigabit Sfp56 (uplink / Stacking) + 2 X 1 Gigabit / 10 Gigabit Sfp+ - Rack-mountable - Poe++
Key Features :
Expansion / Connectivity :
Interfaces :
Power :
Condition : New Factory Sealed
Availability : In Stock
Our Warranty : 90 Days
| Capacity | 48 PORT |
|---|---|
| Condition | New Factory Sealed |
| Manufacturer | HPE |
