HPE P69746-005 DL360 Gen10 4208 1P 64GB-R P408i-a 8SFF 800W PS Server
Part Number:
P69746-005
Got a Big Order or a Quick Question?
Let’s Connect—We Make Tech Buying Effortless.
Let’s Connect—We Make Tech Buying Effortless.
For Govt Institution credit terms or bulk order - Submit your detail below
Note: All heavy items above 20KG will be charged shipping
cost as per actual. Please contact us for a shipping quote before placing
order.
We accept Purchase Orders from Health & Educational
sector and all Government institutions including Councils.
Product Overview 1 (total) / 1 (free) X External Universal Media Bay
8 (total) / 6 (free) X Hot-swap 2.5 Sff
Slots :
1 (total) / 1 (free) X Pcie 3.0 X16 - Three-quarter-length, Full-height
1 (total) / 1 (free) X Pcie 3.0 X8 - Low-profile
1 (total) / 1 (free) X Flexiblelom - Three-quarter-length, Full-height (low-profile)
1 (total) / 1 (free) X Microsd Card (internal)
Interfaces :
1 X HPE Ilo - Type A (1 In Front)
1 X HPE Ilo - Rj-45
5 X Usb 3.0 (1 Front, 2 Rear, 2 Internal)
1 X Vga
4 X Lan (gigabit Ethernet)
Miscellaneous :
Included Accessories : Sff Easy Install Rails
Compliant Standards : Aes, Fips 140-2, Ipv6 Ready, Pci Dss, Tls V1.2, Ashrae Class A4, Ashrae Class A3, Weee 2002/95/ec, Acpi 6.1
Manufacturer Selling Program : HPE Smart Choice
Power :
Device Type : Power Supply - Hot-plug
Power Redundancy : Yes
Power Redundancy Scheme : 1+1
Installed Qty : 2
Max Supported Qty : 2
Voltage Required : Ac 100-120/200-240 V (50/60 Hz)
Power Provided : 800 Watt
80 Plus Certification : 80 Plus Platinum
Operating System / Software :
Os Provided : No Operating System
Os Certified : Centos, Microsoft Windows Server 2012 R2, Vmware Vsphere 6.0 (esxi), Suse Linux Enterprise Server 11 Sp4, Microsoft Windows Server 2016, Red Hat Enterprise Linux 7.3, Red Hat Enterprise Linux 6.9, Vmware Vsphere 6.5 (esxi), Suse Linux Enterprise Server 12 Sp2, Clearos
Sustainability Information :
Energy Star Certified : Yes
Environmental Parameters :
Min Operating Temperature : 50 °f
Max Operating Temperature : 95 °f
Humidity Range Operating : 8 - 90% Rh (non-condensing)
Dimensions & Weight :
Width : 17.1 In
Depth : 27.8 In
Height : 1.7 In
Weight : 28.75 Lbs
Condition : New Cto
Availability : In Stock
Manufacturer Warranty: Full
Our Warranty : 90 Days
HPE P69746-005 Proliant Dl360 Gen10 Smart Choice Model - 2nd Gen 1x Intel Xeon 8-core Silver 4208 / 2.1 Ghz, 64(2x32)gb Ddr4 Sdram, Emb 4x 1gbe Eth Adapter, Smart Array P408i-a Sr Gen10 X8 Lanes 2gb Cache Sas 12g Modular Controller, 2x 480gb Sata Ssd, 8sff, 2x 800w Fs Ps 1u Rack Server.
General Information :
Manufaturer : Hewlett Packard Enterprise
Manufaturer Website Address : WWW.HPE.COM
Manufaturer Part Number : P69746-005
Type : Server - Rack-mountable
Height ( Rack Units) : 1u
Server Scalability : 2-way
Hot-swap Bays Qty : 8
Product Name : HPE Proliant Dl360 Gen10 4208 2.1ghz 8-core 1p 64gb-r P408i-a 8sff 800w Ps Server ( Smart Choice Model)
Processor / Chipset :
Cpu : Intel Xeon Silver 4208
Clock Speed : 2.1 Ghz
Max Turbo Speed : 3.2 Ghz
Number Of Cores : 8-core
Cpu Qty : 1
Max Cpu Qty : 2
Cpu Upgradability : Upgradable
Processor Main Features : Hyper-threading Technology, Intel Turbo Boost Technology
Chipset Type : Intel C621
Cache Memory :
Installed Size : L3 Cache - 11 Mb
Cache Per Processor : 11 Mb
Ram :
Installed Size : 64 Gb / 1.5 Tb (max)
Technology : Ddr4 Sdram
Effective Memory Speed : 2400 Mhz
Rated Memory Speed : 2933 Mhz
Form Factor : Dimm 288-pin
Slots : 24 (total) / 22 (empty)
Features : Registered, Slots 13 - 24 Are Available In Two-processor Configuration Only, HPE Smartmemory
Configuration Features : 2 X 32 Gb
Ram Supported : 3 Tb Load-reduced - Ecc ¦ 1.5 Tb Registered - Ecc ¦ 192 Gb Non-volatile - Ecc
Internal Storage Devices :
Hdd / Ssd :
Type : Ssd - 2.5
Capacity : 2 X 480 Gb
Interface Type : Sata
Optical Drive : No Optical Drive
Storage Controller :
Type : 1 X Raid
Controller Interface Type : Sata 6gb/s / Sas 12gb/s
Storage Controller Name : HPE Smart Array P408i-a
Channel Qty : 8
Buffer Size : 2 Gb
Graphics Controller :
Video Memory : 16 Mb
Video Interfaces : Vga
Networking :
Ethernet Ports : 4 X Gigabit Ethernet
Data Link Protocol : Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol : Snmp 3, Ipmi 2.0, Smash Clp
Remote Management Controller : Integrated Lights-out 5
Features : Wake On Lan (wol), Pxe Support
Expansion / Connectivity :
Bays :
Slots :
Interfaces :
Miscellaneous :
Included Accessories : Sff Easy Install Rails
Compliant Standards : Aes, Fips 140-2, Ipv6 Ready, Pci Dss, Tls V1.2, Ashrae Class A4, Ashrae Class A3, Weee 2002/95/ec, Acpi 6.1
Manufacturer Selling Program : HPE Smart Choice
Power :
Device Type : Power Supply - Hot-plug
Power Redundancy : Yes
Power Redundancy Scheme : 1+1
Installed Qty : 2
Max Supported Qty : 2
Voltage Required : Ac 100-120/200-240 V (50/60 Hz)
Power Provided : 800 Watt
80 Plus Certification : 80 Plus Platinum
Operating System / Software :
Os Provided : No Operating System
Os Certified : Centos, Microsoft Windows Server 2012 R2, Vmware Vsphere 6.0 (esxi), Suse Linux Enterprise Server 11 Sp4, Microsoft Windows Server 2016, Red Hat Enterprise Linux 7.3, Red Hat Enterprise Linux 6.9, Vmware Vsphere 6.5 (esxi), Suse Linux Enterprise Server 12 Sp2, Clearos
Sustainability Information :
Energy Star Certified : Yes
Environmental Parameters :
Min Operating Temperature : 50 °f
Max Operating Temperature : 95 °f
Humidity Range Operating : 8 - 90% Rh (non-condensing)
Dimensions & Weight :
Width : 17.1 In
Depth : 27.8 In
Height : 1.7 In
Weight : 28.75 Lbs
Condition : New Cto
Availability : In Stock
Manufacturer Warranty: Full
Our Warranty : 90 Days
| Capacity | OCTA-CORE XEON 2.10GHz |
|---|---|
| Condition | New |
| Manufacturer | HPE |
