HPE P69320-005 DL380 Gen10 Plus 6326 1P 32GB-R MR416i-a NC 8SFF 800W Server
Part Number:
P69320-005
Got a Big Order or a Quick Question?
Let’s Connect—We Make Tech Buying Effortless.
Let’s Connect—We Make Tech Buying Effortless.
For Govt Institution credit terms or bulk order - Submit your detail below
Note: All heavy items above 20KG will be charged shipping
cost as per actual. Please contact us for a shipping quote before placing
order.
We accept Purchase Orders from Health & Educational
sector and all Government institutions including Councils.
Product Overview 8 (total) / 6 (free) X Hot-swap 2.5 Sff
Slots :
1 (total) / 1 (free) X Pcie 4.0 X16 - Full-length, Full-height
1 (total) / 1 (free) X Pcie 4.0 X16 - Half-length, Full-height (x8 Mode)
1 (total) / 1 (free) X Pcie 4.0 X16 - Full-length, Full-height (x8 Mode)
Interfaces :
1 X HPE Ilo - Rj-45
1 X Usb 3.0
1 X HPE Ilo (service Port)
2 X Lan - Sfp+
1 X Vga
Miscellaneous :
Included Accessories : 6 Maximum Performance Fans, Cpu High Performance Heatsink
Compliant Standards : Aes, Fips 140-2, Weee, Triple Des, Tls V1.2, Ashrae Class A4, Ashrae Class A3, Redfish Api, Uefi, Acpi 6.3, Smbios 3.2
Manufacturer Selling Program : HPE Smart Choice
Pricing Type : Cto
Power :
Device Type : Power Supply - Hot-plug
Power Redundancy : Yes
Power Redundancy Scheme : 1+1
Installed Qty : 2
Max Supported Qty : 2
Voltage Required : Ac 100-120/200-240 V (50/60 Hz)
Power Provided : 800 Watt
80 Plus Certification : 80 Plus Platinum
Operating System / Software :
Os Provided : No Operating System
Software : HPE Ilo Standard With Intelligent Provisioning
Sustainability Information :
Energy Star Certified : Yes
Environmental Parameters :
Min Operating Temperature : 50 °f
Max Operating Temperature : 95 °f
Humidity Range Operating : 8 - 90% Rh (non-condensing)
Dimensions & Weight :
Width : 17.5 In
Depth : 28 In
Height : 3.4 In
Weight : 35.54 Lbs
Condition : New Cto
Availability : In Stock
Manufacturer Warranty: Full
Our Warranty : 90 Days
HPE P69320-005 Proliant Dl380 Gen10 Plus Smart Choice Model - 3rd Gen 1x Intel Xeon 16-core Gold 6326 / 2.9 Ghz, 32(1x32)gb Ddr4 Sdram, Bcm5719 Eth 1gb 4p Base-t Ocp3 Adapter, Mr416i-a Gen10 Plus X16 Lanes 4gb Cache Nvme/sas 12g Controller, 2x 480gb Sata Ssd, 8sff, 2x 800w Fs Ps 2u Rack Server.
General Information :
Manufaturer : Hewlett Packard Enterprise
Manufaturer Website Address : WWW.HPE.COM
Manufaturer Part Number : P69320-005
Type : Server - Rack-mountable
Height ( Rack Units) : 2u
Server Scalability : 2-way
Hot-swap Bays Qty : 8
Product Name : HPE Proliant Dl380 Gen10 Plus 6326 2.9ghz 16-core 1p 32gb-r Mr416i-a Nc 8sff 800w Ps Server ( Smart Choice Model)
Processor / Chipset :
Cpu : Intel Xeon Gold 6326
Clock Speed : 2.9 Ghz
Max Turbo Speed : 3.5 Ghz
Number Of Cores : 16-core
Cpu Qty : 1
Max Cpu Qty : 2
Cpu Upgradability : Upgradable
Processor Main Features : Hyper-threading Technology, Intel Turbo Boost Technology
Chipset Type : Intel C621a
Cache Memory :
Installed Size : L3 Cache - 24 Mb
Cache Per Processor : 24 Mb
Ram :
Installed Size : 32 Gb
Technology : Ddr4 Sdram
Effective Memory Speed : 3200 Mhz
Rated Memory Speed : 3200 Mhz
Form Factor : Dimm 288-pin
Slots : 32 (total) / 31 (empty)
Features : Registered, Hp Smartmemory, Slots 17 - 32 Are Available In Two-processor Configuration Only
Configuration Features : 1 X 32 Gb
Ram Supported : Optane Dc Persistent
Internal Storage Devices :
Hdd / Ssd :
Type : Ssd - 2.5
Capacity : 2 X 480 Gb
Interface Type : Sata
Optical Drive : No Optical Drive
Storage Controller :
Type : 1 X Raid
Controller Interface Type : Sas 12gb/s
Storage Controller Name : HPE Smart Array P408i-a Sr Gen10
Channel Qty : 8
Buffer Size : 2 Gb
Card Reader :
Type : Card Reader
Supported Flash Memory Cards : Microsd
Graphics Controller :
Video Memory : 16 Mb
Video Interfaces : Vga
Networking :
Ethernet Ports : 4 X Gigabit Ethernet
Ethernet Controller : Broadcom Bcm5719
Data Link Protocol : Gigabit Ethernet
Remote Management Controller : Integrated Lights-out 5
Expansion / Connectivity :
Bays :
Slots :
Interfaces :
Miscellaneous :
Included Accessories : 6 Maximum Performance Fans, Cpu High Performance Heatsink
Compliant Standards : Aes, Fips 140-2, Weee, Triple Des, Tls V1.2, Ashrae Class A4, Ashrae Class A3, Redfish Api, Uefi, Acpi 6.3, Smbios 3.2
Manufacturer Selling Program : HPE Smart Choice
Pricing Type : Cto
Power :
Device Type : Power Supply - Hot-plug
Power Redundancy : Yes
Power Redundancy Scheme : 1+1
Installed Qty : 2
Max Supported Qty : 2
Voltage Required : Ac 100-120/200-240 V (50/60 Hz)
Power Provided : 800 Watt
80 Plus Certification : 80 Plus Platinum
Operating System / Software :
Os Provided : No Operating System
Software : HPE Ilo Standard With Intelligent Provisioning
Sustainability Information :
Energy Star Certified : Yes
Environmental Parameters :
Min Operating Temperature : 50 °f
Max Operating Temperature : 95 °f
Humidity Range Operating : 8 - 90% Rh (non-condensing)
Dimensions & Weight :
Width : 17.5 In
Depth : 28 In
Height : 3.4 In
Weight : 35.54 Lbs
Condition : New Cto
Availability : In Stock
Manufacturer Warranty: Full
Our Warranty : 90 Days
| Capacity | 16-CORE XEON GOLD 2.9GHz |
|---|---|
| Condition | New |
| Manufacturer | HPE |
