HPE P69303-005 ML110 Gen11 4410Y 32GB-R MR408i-o 8SFF 2x480GB SSD 2x800W RPS AMS Server
Part Number:
P69303-005
Got a Big Order or a Quick Question?
Let’s Connect—We Make Tech Buying Effortless.
Let’s Connect—We Make Tech Buying Effortless.
For Govt Institution credit terms or bulk order - Submit your detail below
Note: All heavy items above 20KG will be charged shipping
cost as per actual. Please contact us for a shipping quote before placing
order.
We accept Purchase Orders from Health & Educational
sector and all Government institutions including Councils.
Product Overview 1 (total) / 1 (free) X External 5.25
8 (total) / 8 (free) X Hot-swap 2.5 Sff
Slots :
2 (total) / 2 (free) X Pcie 5.0 X16
1 (total) / 1 (free) X Pcie 5.0 X16 / Open Compute Project Mezzanine (ocp) 3.0 (x16 Mode)
Interfaces :
1 X Vga
2 X Lan (gigabit Ethernet)
1 X HPE Ilo - Rj-45 (1 Rear)
3 X Usb 3.0 (1 Front, 2 Rear)
1 X HPE Ilo - Type A (1 In Front)
Miscellaneous :
Included Accessories : 2 Non-hot Plug Standard Fans
Compliant Standards : Aes, Weee, Triple Des, Tls V1.2, Ashrae Class A4, Ashrae Class A3, Redfish Api, Uefi, Fips 140-3, Acpi 6.4, Smbios 3.4
Manufacturer Selling Program : Cto
Power :
Device Type : Power Supply - Hot-plug
Power Redundancy : Optional
Power Redundancy Scheme : 1+1 (with Optional Power Supply)
Installed Qty : 1
Max Supported Qty : 2
Voltage Required : Ac 100-120/200-240 V (50/60 Hz)
Power Provided : 800 Watt
80 Plus Certification : 80 Plus Platinum
Operating System / Software :
Software : HPE Ilo Standard With Intelligent Provisioning, HPE Oneview Standard (free Download)
Environmental Parameters :
Min Operating Temperature : 50 °f
Max Operating Temperature : 95 °f
Humidity Range Operating : 8 - 90% Rh (non-condensing)
Dimensions & Weight :
Width : 7.7 In
Depth : 23.1 In
Height : 18.2 In
Weight : 44.31 Lbs
Condition : New Cto
Availability : In Stock
Manufacturer Warranty: Full
Our Warranty : 90 Days
HPE P69303-005 Proliant Ml110 Gen11 Pre-configured Model - 4th Gen 1x Intel Xeon 12-core Silver 4410y / 2.0 Ghz, 32(1x32)gb Ddr5 Sdram, Broadcom Bcm5720 Ethernet 1gb 2-port Base-t Adapter, HPE Mr408i-o Gen11 X8 Lanes 4gb Cache Ocp Spdm Storage Controller, 8sff, 2x 800w Fs Ps 4.5u Tower Server.
General Information :
Manufaturer : Hewlett Packard Enterprise
Manufaturer Website Address : WWW.HPE.COM
Manufaturer Part Number : P69302-005
Product Form Factor : Rack-mountable - 4.5u
Height ( Rack Units) : 4.5u
Server Scalability : 1-way
Hot-swap Bays Qty : 8
Product Name : HPE Proliant Ml110 Gen11 4410y 12-core 1p 32gb-r Mr408i-o 8sff 2x480gb Ssd 2x800w Rps Ams Server ( Pre-configured Model)
Processor / Chipset :
Cpu : Intel Xeon Silver 4410y
Clock Speed : 2 Ghz
Max Turbo Speed : 3.9 Ghz
Number Of Cores : 12-core
Cpu Qty : 1
Max Cpu Qty : 1
Cpu Upgradability : Upgradable
Processor Main Features : Hyper-threading Technology, Intel Turbo Boost Technology 2
Cpu Socket : Lga4677 Socket-e
Chipset Type : Intel C741
Cache Memory :
Installed Size : L3 Cache - 30 Mb
Cache Per Processor : 30 Mb
Ram :
Installed Size : 32 Gb / 1 Tb (max)
Technology : Ddr5 Sdram - Advanced Ecc
Effective Memory Speed : 4400 Mhz
Rated Memory Speed : 4800 Mhz
Form Factor : Dimm 288-pin
Slots : 16 (total) / 15 (empty)
Features : Registered, HPE Smartmemory
Configuration Features : 1 X 32 Gb
Internal Storage Devices :
Hdd / Ssd :
Type : Ssd - M.2
Capacity : 2 X 480 Gb
Interface Type : Pci Express 3.0 X8 (nvme)
Features : Raid 1 - Factory Configured, Boot Drive, Nvm Express (nvme)
Optical Drive : No Optical Drive
Storage Controller :
Type : 1 X Raid - Ocp
Controller Interface Type : Serial Ata-600 / Sas 3.0 / Pci Express (nvme)
Storage Controller Name : HPE Mr408i-o Gen11 Spdm
Channel Qty : 8
Raid Level : Raid 0, Raid 1, Raid 5, Raid 6, Raid 10, Raid 50, Raid 60
Buffer Size : 4 Gb
Storage Controller (2nd) :
Type : 2 X Nvme - Pcie 3.0 X8
Controller Interface Type : Nvm Express
Storage Controller Name : HPE Ns204i-p
Channel Qty : 2
Graphics Controller :
Video Memory : 16 Mb
Video Interfaces : Vga
Networking :
Ethernet Ports : 2 X Gigabit Ethernet
Ethernet Controller : Broadcom Bcm5720
Data Link Protocol : Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol : Snmp 3, Ipmi 2.0
Remote Management Controller : Integrated Lights-out 6
Features : Wake On Lan (wol), Acpi Support, Pxe Support
Expansion / Connectivity :
Bays :
Slots :
Interfaces :
Miscellaneous :
Included Accessories : 2 Non-hot Plug Standard Fans
Compliant Standards : Aes, Weee, Triple Des, Tls V1.2, Ashrae Class A4, Ashrae Class A3, Redfish Api, Uefi, Fips 140-3, Acpi 6.4, Smbios 3.4
Manufacturer Selling Program : Cto
Power :
Device Type : Power Supply - Hot-plug
Power Redundancy : Optional
Power Redundancy Scheme : 1+1 (with Optional Power Supply)
Installed Qty : 1
Max Supported Qty : 2
Voltage Required : Ac 100-120/200-240 V (50/60 Hz)
Power Provided : 800 Watt
80 Plus Certification : 80 Plus Platinum
Operating System / Software :
Software : HPE Ilo Standard With Intelligent Provisioning, HPE Oneview Standard (free Download)
Environmental Parameters :
Min Operating Temperature : 50 °f
Max Operating Temperature : 95 °f
Humidity Range Operating : 8 - 90% Rh (non-condensing)
Dimensions & Weight :
Width : 7.7 In
Depth : 23.1 In
Height : 18.2 In
Weight : 44.31 Lbs
Condition : New Cto
Availability : In Stock
Manufacturer Warranty: Full
Our Warranty : 90 Days
| Capacity | 12-CORE XEON SILVER 2.0GHz |
|---|---|
| Condition | New |
| Manufacturer | HPE |
