HPE P40102-001 Slingshot 200Gb 64-port QSFP-DD 1U Switch
Part Number:
P40102-001
Got a Big Order or a Quick Question?
Let’s Connect—We Make Tech Buying Effortless.
Let’s Connect—We Make Tech Buying Effortless.
For Govt Institution credit terms or bulk order - Submit your detail below
Note: All heavy items above 20KG will be charged shipping
cost as per actual. Please contact us for a shipping quote before placing
order.
We accept Purchase Orders from Health & Educational
sector and all Government institutions including Councils.
Product Overview Is Your Hpc Networking Solution Able To Meet Your Converged Workload Needs For Today And Tomorrow?
HPE Slingshot Provides A Modern, High-performance Interconnect For Hpc And Ai Clusters That Delivers High-bandwidth And Low-latency For Hpc, Ml, And Analytics Applications By Bringing Together The Specialized Requirements Of Hpc-optimized Fabrics With The Ubiquity Of Ethernet. This Delivers A Converged Infrastructure With High-performance On Both Hpc Simulation Codes And Native Ip Applications, With Efficient Scalable Access To Data Sources.
Building On Crays Specialized Silicon, HPE Slingshot Delivers Consistent Performance And Low Latency Under Load And At Scale. This Prepares You To Efficiently Service Increasingly Diverse Users Taking Advantage Of Your Hpc Resources, And Do So Without Overprovisioning Bandwidth Or Deploying Multiple Systems To Avoid Congestion On Your Most Demanding Workloads.
Technical Specifications
Form Factor 1u Enclosure For 19” Rack, Fixed Rails Included.
Dimensions 1.7 X 19 X 27in (h X W X D) (4.3cm X 48.3 Cm X 68.6 Cm)
Weight 35lbs (15.88 Kg)
Physical Connectivity 32 Qsfp-dd
Port Capability – 200 Gbps
Ieee 802.3cd/bs (200 Gbps) Ethernet Over 4 X 50 Gb/s (pam-4) Lanes
200gbase-sr4, Up To 100m Multi-mode Fiber
200gbase-cr4, Up To 3m Copper Cable
Port Capability – 100 Gbps
Ieee 802.3 2018 100 Gbps Ethernet Over 4 X 25 Gb/s (nrz) Lanes
100gbase-cr4, 5m Copper Cable
100gbase-sr4, 100m Multi-mode Fiber
Ethernet
Optimized Ethernet And Hpc Fabric Formats
Link Level Retry, Low Latency Fec
Lossy And Lossless Delivery
Flow Control, 802.1x (paus), 802.1p (pfc), Credit-based Flow Control On Fabric Links, Fine Grain Flow Control On Host Links End Edge Ports
Quality Of Service
Ietf Diffserv Or Ieee 802.1p/q
Patented Hardware Congestion Management Mechanisms
Routing
Packet-by-packet Adaptive Routing With Real-time Feedback On Load
Order-preserving Adaptive Routing Of Ip Flows
Traffic Class Specfic Routing
Management Ports 1gb Rj-45, 10gb Rj-45
Management Leds Power And Status
Throughput Per Port Line Rate
Port Status Link And Activity
Power And Cooling
Two (1+1 Redundant) Hot Plug Power Supplies
Five Hot Plug Fan Modules (n + 1 Redundant).
Power 180-264v – Inlet Connector Iec320 C-14 10a/250vac
240vac Typical – No 120vac Or 277 Vac Support. Frequency 50-60hz
Power Draw: 481w +12.5w Per Active Optical Cable When All Fabric Ports Are Attached To Compute Nodes And Running At Full Bandwidth. Includes Fan Power, All Vr Conversion, And Copper Losses.
Airflow Is From The Power Supply Side To The Port Connector Side.
94.5 Cfm At 2.6” Of Water Pressure At Maximum Fan Speed With All Qsfp-dd Cable Ports Populated
Accoustic Sounds Pressure While Operating At Maximum Fan Speed Is 73.5 Dba (iso 7779 Bystander Method)
Environmentals
Temperature Ranges
Maximum Operating Dry Bulb Temperature Range: 5c To 35c
Recommended Operating Dry Bulb Temperature: 18c To 25c
Maximum Non-operating Dry Bulb Temperature Range: 5c To 45c
Relative Humidity Specification (for Ambient Air)
Maximum Operating Relative Humidity Range: 8% (-12c Dew Point) To 85% Noncondensing
Recommended Operating Relative Humidity Range: 30% To 50% Non-condensing
Maximum Non-operating Relative Humidity Range: 8% To 80% Non-condensing
Maximum Dew Point: 27c
Condition: New Factory Sealed.
Availability: Call.
Our Warranty: 90 Days.
HPE P40102-001 Slingshot 200gb 64-port Qsfp-dd 1u Switch
Overview
Technical Specifications
Form Factor 1u Enclosure For 19” Rack, Fixed Rails Included.
Dimensions 1.7 X 19 X 27in (h X W X D) (4.3cm X 48.3 Cm X 68.6 Cm)
Weight 35lbs (15.88 Kg)
Physical Connectivity 32 Qsfp-dd
Port Capability – 200 Gbps
Port Capability – 100 Gbps
Ethernet
Quality Of Service
Routing
Management Ports 1gb Rj-45, 10gb Rj-45
Management Leds Power And Status
Throughput Per Port Line Rate
Port Status Link And Activity
Power And Cooling
Accoustic Sounds Pressure While Operating At Maximum Fan Speed Is 73.5 Dba (iso 7779 Bystander Method)
Environmentals
Temperature Ranges
Relative Humidity Specification (for Ambient Air)
Condition: New Factory Sealed.
Availability: Call.
Our Warranty: 90 Days.
| Capacity | 64 PORT |
|---|---|
| Condition | New Factory Sealed |
| Manufacturer | HPE |
