Dell Networking N3132PX-ON Managed Rack Mountable Switch
Part Number:
N3132PX-ON
Got a Big Order or a Quick Question?
Let’s Connect—We Make Tech Buying Effortless.
Let’s Connect—We Make Tech Buying Effortless.
For Govt Institution credit terms or bulk order - Submit your detail below
Note: All heavy items above 20KG will be charged shipping
cost as per actual. Please contact us for a shipping quote before placing
order.
We accept Purchase Orders from Health & Educational
sector and all Government institutions including Councils.
Product Overview
Key Features :
Device Type : Switch 32 Ports L3 Managed Stackable
Enclosure Type : Rack-mountable 1u
Subtype : Gigabit Ethernet
Ports : 24 X 10/100/1000 (poe) + 8 X 100/1000/2.5g/5g (poe) + 4 X 10 Gigabit Sfp+
> Power Over Ethernet (poe) : Poe
Performance : Switching Fabric Bandwidth: 328 Gbps , Forwarding Performance: 428 Mpps
Capacity : Mac Addresses: 32000 , Aggregated Links (dynamic): 144 , Lag Groups: 128 , Queues Per Port: 8 , Vlans Supported: 4094 , Arp Entries: 6144 , Ndp Entries: 400 , Max Acl Rules System-wide: 4096 , Acl: 100 , Maximum Acl Rules Per Interface (ipv4) Ingress Rules: 3072 , Maximum Acl Rules Per Interface (ipv4) Egress Rules: 1024 , Maximum Acl Rules Per Interface (ipv6) Ingress Rules: 1021 , Maximum Acl Rules Per Interface (ipv6) Egress Rules: 512 , Multicast Entries (ipv4): 1536 , Multicast Entries (ipv6): 512 , Ospf Routes: 8160
Mac Address Table Size : 32000 Entries
Routing Protocol : Igmpv2, Igmp, Pim-sm, Pim-dm, Igmpv3, Mldv2, Mld
Remote Management Protocol : Snmp 2, Rmon 1, Rmon 2, Snmp, Rmon 3, Rmon 9, Telnet, Http, Tftp, Ssh-2
Encryption Algorithm : Aes, Ssl, Tls 1.0
Authentication Method : Radius, Tacacs+, Ldap
Features : Mdi/mdi-x Switch, Auto-negotiation, Port Mirroring, Ip Address Filtering, Access Control List (acl) Support, Quality Of Service (qos), Front To Back Airflow, Lldp Support, Remote Switch Port Analyzer (rspan), Management Information Base (mib), Dual Firmware Images, Redundant Fans, Mac And Ip-based Acls Support, Time-controlled Acls Support
compliant Standards : Ieee 802.2, Ieee 802.3, Ieee 802.3u, Ieee 802.3z, Ieee 802.1d, Ieee 802.1q, Ieee 802.3ab, Ieee 802.1p, Ieee 802.3x, Ieee 802.3ad (lacp), Ieee 802.1w, Ieee 802.1x, Ieee 802.3ae, Ieee 802.3ac, Ieee 802.1s, Ieee 802.1v, Ansi/tia-1057, Ieee 802.1ab (lldp), Ieee 802.3at, Ieee 802.3az, Ieee 802.3ax
Ram : 2 Gb
Flash Memory : 512 Mb
Expansion / Connectivity :
Interfaces :
24 X Gigabit Lan - Rj-45 - Poe
8 X 5gbit Lan - Rj-45 - Poe
4 X 10gbit Lan - Sfp+
1 X 1000base-t - Rj-45 - Management
1 X Usb - Type A
Power :
Power Device : Internal Power Supply - Hot-plug
Installed Qty : 1 (installed) / 2 (max)
Power Provided : 1100 Watt
Condition : Refurbished.
Availability : In Stock.
Our Warranty : 90 Days
DELL N3132PX-ON Emc Networking N3132PX-ON Switch 32 Ports Managed Rack-mountable
Key Features :
compliant Standards : Ieee 802.2, Ieee 802.3, Ieee 802.3u, Ieee 802.3z, Ieee 802.1d, Ieee 802.1q, Ieee 802.3ab, Ieee 802.1p, Ieee 802.3x, Ieee 802.3ad (lacp), Ieee 802.1w, Ieee 802.1x, Ieee 802.3ae, Ieee 802.3ac, Ieee 802.1s, Ieee 802.1v, Ansi/tia-1057, Ieee 802.1ab (lldp), Ieee 802.3at, Ieee 802.3az, Ieee 802.3ax
Expansion / Connectivity :
Interfaces :
Power :
Condition : Refurbished.
Availability : In Stock.
Our Warranty : 90 Days
| Capacity | 32 PORT |
|---|---|
| Condition | Refurbished |
| Manufacturer | DELL |
