Samsung MZWMO61THCLF BM1743 61.44TB 2.5Inch U.2 PCI Express Gen.4 x4 Ssd.
Part Number:
MZWMO61THCLF
Got a Big Order or a Quick Question?
Let’s Connect—We Make Tech Buying Effortless.
Let’s Connect—We Make Tech Buying Effortless.
For Govt Institution credit terms or bulk order - Submit your detail below
Note: All heavy items above 20KG will be charged shipping
cost as per actual. Please contact us for a shipping quote before placing
order.
We accept Purchase Orders from Health & Educational
sector and all Government institutions including Councils.
Product Overview
General Information :
Manufacturer : SAMSUNG
Manufacturer Part Number : MZWMO61THCLF
Product Series : Bm1743
Product Type : Solid State Drive
Technical Information :
Pci Express Gen.4
Pci Express Base Specification Rev. 4.0
Nvm Expresstm Specification Rev. 1.4b
Nvm Expresstm Management Interface Specification Rev. 1.1b
Single Port X4 Lanes/ Dual Port X2 Lanes
Enhanced Power-loss Data Protection
End-to-end Data Protection
Support Ssd Enhanced S.m.a.r.t. Feature Set
Hardware Based Aes-xts 256-bit Encryption Engine
Static And Dynamic Wear Leveling
Rohs / Halogen-free Compliant
Capacity: 61.44tb
Drive Configuration :
From Factor: 2.5-inch, U.2
Interface: Pci Express Gen.4 X4 Bytes Per Sector: 512(default), 520, 4096, 4104, 4112, 4160bytes
Performance Specifications :
Data Transfer Rate (128kb Data Size): Sequential Read: Up To 7,200 Mb/s, Sequential Write: Up To 2,100 Mb/s
Data I/o Speed (4kb Data Size, Sustained): Random Read: Up To 400kiops, Random Write: Up To 30kiops
Latency (sustained Workload): Read / Write (typical): 150 Us/ 30 Us, Drive Ready Time (typical) Up To 1 Sec
Quality Of Service: Read / Write (99%): Up To 200 Us/ 50 Us
Reliability Specifications :
Uncorrectable Bit Error Rate: 1 Sector Per 10^17 Bits Read
Mtbf: 2,500,000 Hours
Endurance: 0.26 Dwpd
Tbw (@jedec Workload): 29.153 Pb
Data Retention: 3 Month
Environmental Specifications :
Temperature: Operating (tcomp): 0 ~ 70 °c, Non-operating -40 ~ 85 °c
Humidity (non-condensing): 5 ~ 95%
Shock: Non-operating/ Operating: 1,500 G / 0.5msec
Vibration (20~2,000hz, Sweep Sine): Non-operating/ Operating: 20g
Power Requirements: Supply Voltage / Tolerance: 12v +/- 10%
Power Consumptions :
Read Power: 23.8 W
Write Power: 24.7 W
Idle (typ.): 5 W
Physical Dimension :
Width: 69.85 +/- 0.25mm
Length: 100.20 +/- 0.25mm
Height: 15.00 +0.00/-0.50mm
Weight: Up To 163 G
Condition : Brand New.
Availability : In Stock.
Server Supply Warranty : 90 Days.
SAMSUNG Bm1743 61.44tb 2.5inch U.2 Pci Express Gen.4 X4 Internal Solid State Drive.
General Information :
Technical Information :
Drive Configuration :
Performance Specifications :
Reliability Specifications :
Environmental Specifications :
Power Consumptions :
Physical Dimension :
Condition : Brand New.
Availability : In Stock.
Server Supply Warranty : 90 Days.
| Capacity | 61.44TB |
|---|---|
| Condition | Brand New |
| Manufacturer | SAMSUNG |
