Samsung BM1743 MZWMO61THCLF-00AW7 61.44TB Pci Express Gen.4 x4 Brand New
Part Number:
MZWMO61THCLF-00AW7
Got a Big Order or a Quick Question?
Let’s Connect—We Make Tech Buying Effortless.
Let’s Connect—We Make Tech Buying Effortless.
For Govt Institution credit terms or bulk order - Submit your detail below
Note: All heavy items above 20KG will be charged shipping
cost as per actual. Please contact us for a shipping quote before placing
order.
We accept Purchase Orders from Health & Educational
sector and all Government institutions including Councils.
Product Overview Product Description : SAMSUNG Bm1743 MZWMO61THCLF-00AW7 - Solid State Drive - 61.44 Tb - Pci Express Gen.4 X4 (nvme)
Type : Solid State Drive - Internal
Capacity : 61.44 Tb
Form Factor : 2.5-inch, U.2
Interface : Pci Express 4.0 X4 (nvme)
Sed Encryption : Tcg Opal 2.0
Pci Express Base Specification Rev. 4.0
Nvm Expresstm Specification Rev. 1.4b
Nvm Expresstm Management Interface Specification Rev. 1.1b
Single Port X4 Lanes/ Dual Port X2 Lanes
Enhanced Power-loss Data Protection
End-to-end Data Protection
Support Ssd Enhanced S.m.a.r.t. Feature Set
Hardware Based Aes-xts 256-bit Encryption Engine
Static And Dynamic Wear Leveling
Rohs / Halogen-free Compliant
Extended Specifications :
Device Type : Solid State Drive - Internal
Capacity : 61.44 Tb
Form Factor : 2.5-inch, U.2
Interface : Pci Express 4.0 X4 (nvme)
Performance Specifications :
Endurance : 29,153 Tb
Internal Data Rate : 14,200 Mbps (read) / 2,100 Mbps (write)
Random Read : 850,000 Iops
Random Write : 30,000 Iops
Latency (random) Read / Write: 150 Us/ 30 Us
Reliability Specifications :
Mtbf : 2,500,000 Hours
Uncorrectable Bit Error Rate (uber) : 1 Sector Per 10^17 Bits Read
Endurance: 0.26 Dwpd
Tbw (@jedec Workload): 29.153 Pb
Data Retention: 3 Month
Environmental Specifications :
Temperature: Operating (tcomp): 0 ~ 70 °c, Non-operating -40 ~ 85 °c
Humidity (non-condensing): 5 ~ 95%
Shock: Non-operating/ Operating: 1,500 G / 0.5msec
Vibration (20~2,000hz, Sweep Sine): Non-operating/ Operating: 20g
Power Requirements: Supply Voltage / Tolerance: 12v +/- 10%
Power Consumptions :
Read Power: 23.8 W
Write Power: 24.7 W
Idle (typ.): 5 W
Physical Dimension :
Width: 69.85 +/- 0.25mm
Length: 100.20 +/- 0.25mm
Height: 15.00 +0.00/-0.50mm
Weight: Up To 163 G
Condition : Brand New.
Availability : In Stock.
Mfg Warranty : None.
Server Supply Warranty : 90 Days.
Main Specifications:
Extended Specifications :
Performance Specifications :
Reliability Specifications :
Environmental Specifications :
Power Consumptions :
Physical Dimension :
Condition : Brand New.
Availability : In Stock.
Mfg Warranty : None.
Server Supply Warranty : 90 Days.
| Capacity | 61.44TB |
|---|---|
| Condition | Brand New |
| Manufacturer | SAMSUNG |
