Samsung BM1743 MZWMO15THCLF-00AW7 15.36TB 2.5Inch U.2 PCI Express Gen.4 x4 Brand New
Part Number:
MZWMO15THCLF-00AW7
Got a Big Order or a Quick Question?
Let’s Connect—We Make Tech Buying Effortless.
Let’s Connect—We Make Tech Buying Effortless.
For Govt Institution credit terms or bulk order - Submit your detail below
Note: All heavy items above 20KG will be charged shipping
cost as per actual. Please contact us for a shipping quote before placing
order.
We accept Purchase Orders from Health & Educational
sector and all Government institutions including Councils.
Product Overview Pci Express Gen.4
Pci Express Base Specification Rev. 4.0
Nvm Expresstm Specification Rev. 1.4b
Nvm Expresstm Management Interface Specification Rev. 1.1b
Single Port X4 Lanes/ Dual Port X2 Lanes
Enhanced Power-loss Data Protection
End-to-end Data Protection
Support Ssd Enhanced S.m.a.r.t. Feature Set
Hardware Based Aes-xts 256-bit Encryption Engine
Static And Dynamic Wear Leveling
Rohs / Halogen-free Compliant
Capacity: 15.36tb
Drive Configuration :
From Factor: 2.5-inch, U.2
Interface: Pci Express Gen.4 X4
Bytes Per Sector: 512(default), 520, 4096, 4104, 4112, 4160bytes
Performance Specifications :
Data Transfer Rate (128kb Data Size): Sequential Read: Up To 7,300 Mb/s, Sequential Write: Up To 1,400 Mb/s
Data I/o Speed (4kb Data Size, Sustained): Random Read: Up To 1,500kiops, Random Write: Up To 80 Kiops
Latency (sustained Workload): Read / Write (typical): Up To 150 Us/ 20 Us, Drive Ready Time (typical) Up To 1 Sec
Quality Of Service: Read / Write (99%): Up To 200 Us/ 25 Us
Reliability Specifications :
Uncorrectable Bit Error Rate: 1 Sector Per 10^17 Bits Read
Mtbf: 2,500,000 Hours
Endurance: 0.26 Dwpd
Tbw (@jedec Workload): 7.288 Pb
Data Retention: 3 Month
Environmental Specifications :
Temperature: Operating (tcomp): 0 ~ 70 °c, Non-operating -40 ~ 85 °c
Humidity (non-condensing): 5 ~ 95%
Shock: Non-operating/ Operating: 1,500 G / 0.5msec
Vibration (20~2,000hz, Sweep Sine): Non-operating/ Operating: 20g
Power Requirements: Supply Voltage / Tolerance: 12v +/- 10%
Power Consumptions :
Read Power: 23.8 W
Write Power: 24.7 W
Idle (typ.): 5 W
Physical Dimension :
Width: 69.85 +/- 0.25mm
Length: 100.20 +/- 0.25mm
Height: 15.00 +0.00/-0.50mm
Weight: Up To 159.2 G
Condition : Brand New.
Availability : In Stock.
Mfg Warranty : None.
Server Supply Warranty : 90 Days.
Features :
Drive Configuration :
Performance Specifications :
Reliability Specifications :
Environmental Specifications :
Power Consumptions :
Physical Dimension :
Condition : Brand New.
Availability : In Stock.
Mfg Warranty : None.
Server Supply Warranty : 90 Days.
| Capacity | 15.36TB |
|---|---|
| Condition | Brand New |
| Manufacturer | SAMSUNG |
