Nvidia MMA1B00-E100 IB EDR up to 100Gb/s QSFP28 MPO 850nm up to 100m Transceiver Ref
Part Number:
MMA1B00-E100
Got a Big Order or a Quick Question?
Let’s Connect—We Make Tech Buying Effortless.
Let’s Connect—We Make Tech Buying Effortless.
For Govt Institution credit terms or bulk order - Submit your detail below
Note: All heavy items above 20KG will be charged shipping
cost as per actual. Please contact us for a shipping quote before placing
order.
We accept Purchase Orders from Health & Educational
sector and all Government institutions including Councils.
Product Overview NVIDIA MMA1B00-E100 Pluggable Optical Transceiver Is Designed For Use In 100gb/s Infiniband Link Protocol Applications
This Sff-8665 Compliant Transceiver Is A Flexible Alternative To An Active Optical Cable (aoc), As It Combines High Port Density And Configurability
with Longer Reach Than Passive Copper Cables In The Data Centers. The Mma1b00 Transceiver Has A Standard Qsfp28 Port On The Electrical Side Towards The Host System
The Optical Cable Is Attached Via A Standard Mpo Connector. The Optical Interface Comprises Four Optical Beams/fibers In Each Direction, Intended
for Multimode Optical Cable Attachments. Each Fiber/beam Operates At Signaling Rates Up To 25.78125gbd
Key Features
Up To 100gb/s
Programmable Rx Output Amplitude
Programmable Rx Output Emphasis
Programmable Tx Input Equalizer
Selectable Retiming
Sff-8665 Compliant
3.3v Power Supply
Qsfp28 Power Class 3
Class 1 Laser Safety
Maximum Link Length Of 70m On Om3, And 100m On Om4 Multimode Fiber At 100gb/s
Hot Pluggable
Rohs Compliant
Ieee 802.3 100gbase-sr4 Compliant
Ic Management Interface
Condition: Refurbished.
Availability: In Stock.
Our Warranty: 90 Days.
NVIDIA MMA1B00-E100 Ib Edr Up To 100gb/s Qsfp28 Mpo 850nm Up To 100m Transceiver
Introduction
with Longer Reach Than Passive Copper Cables In The Data Centers. The Mma1b00 Transceiver Has A Standard Qsfp28 Port On The Electrical Side Towards The Host System
for Multimode Optical Cable Attachments. Each Fiber/beam Operates At Signaling Rates Up To 25.78125gbd
Key Features
Condition: Refurbished.
Availability: In Stock.
Our Warranty: 90 Days.
| Capacity | 100 GIGABIT |
|---|---|
| Condition | Refurbished |
| Manufacturer | NVIDIA |
