NVIDIA MCX75510AAS-NEAT ConnectX-7 adapter card 400Gb/s NDR IB Single-port OSFP PCIe 5.0 x16 with x16 Extension option (Socket Direct ready) Secure boot No Crypto
Part Number:
MCX75510AAS-NEAT
Got a Big Order or a Quick Question?
Let’s Connect—We Make Tech Buying Effortless.
Let’s Connect—We Make Tech Buying Effortless.
For Govt Institution credit terms or bulk order - Submit your detail below
Note: All heavy items above 20KG will be charged shipping
cost as per actual. Please contact us for a shipping quote before placing
order.
We accept Purchase Orders from Health & Educational
sector and all Government institutions including Councils.
Product Overview Gen 5.0/4.0: Serdes @ 16/32gt/s, X16 Lanes (4.0 And 3.0 Compatible)
Optional: Additional Pcie X16 Gen 4.0 @ Serdes 16gt/s Through The Pcie Auxiliary Passive Card And Cabline Sa-ii Plus Harnesses
Networking Ports Single Osfp Infiniband
Data Rate
Infiniband Ndr/ndr200/hdr/hdr100/edr/fdr/sdr
Ethernet (default Mode) 400/200/100/50/25/10 Gb/s
Protocol Support
Infiniband Ibta V1.5a
Auto-negotiation Ndr (4 Lanes X 100gb/s Per Lane) Port, Ndr200 (2 Lanes X 100gb/s Per Lane) Port, Hdr (50gb/s Per Lane) Port, Hdr100 (2 Lane X 50gb/s Per Lane), Edr (25gb/s Per Lane) Port, Fdr (14.0625gb/s Per Lane), 1x/2x/4x Sdr (2.5gb/s Per Lane)
Capabilities Secure Boot Enabled, Crypto Disabled
Electrical And Thermal Specifications
Voltage 12v, 3.3vaux
Maximum Current 100ma
Typical Power With Passive Cables In Pcie Gen 5.0 X16 24.9w
Environmental
Temperature
Operational: 0°c To 55°c
Non-operational: -40°c To 70°c
Humidity
Operational: 10% To 85%
Non-operational 10% To 90%
Rohs Rohs Compliant
Condition: New Factory Sealed.
Availability: In Stock.
Our Warranty: 90 Days.
NVIDIA MCX75510AAS-NEAT Connectx-7 Adapter Card 400gb/s Ndr Ib Single-port Osfp Pcie 5.0 X16 With X16 Extension Option (socket Direct Ready) Secure Boot No Crypto Full-height Bracket
Specifications
Physical
Adapter Card Size Pcie Half Height, Half Length 2.71 In. X 6.6 In. (68.90mm X 167.65 Mm)
Auxiliary Pcie Connection Card Size 5.09 In. X 2.32 In. (129.30mm X 59.00mm) Two Cabline Ca-ii Plus Harnesses (white And Black).
Interfaces
Pci Express Interface
Networking Ports Single Osfp Infiniband
Data Rate
Infiniband Ndr/ndr200/hdr/hdr100/edr/fdr/sdr
Ethernet (default Mode) 400/200/100/50/25/10 Gb/s
Protocol Support
Infiniband Ibta V1.5a
Auto-negotiation Ndr (4 Lanes X 100gb/s Per Lane) Port, Ndr200 (2 Lanes X 100gb/s Per Lane) Port, Hdr (50gb/s Per Lane) Port, Hdr100 (2 Lane X 50gb/s Per Lane), Edr (25gb/s Per Lane) Port, Fdr (14.0625gb/s Per Lane), 1x/2x/4x Sdr (2.5gb/s Per Lane)
Capabilities Secure Boot Enabled, Crypto Disabled
Electrical And Thermal Specifications
Voltage 12v, 3.3vaux
Maximum Current 100ma
Typical Power With Passive Cables In Pcie Gen 5.0 X16 24.9w
Environmental
Temperature
Humidity
Rohs Rohs Compliant
Condition: New Factory Sealed.
Availability: In Stock.
Our Warranty: 90 Days.
| Capacity | 1 PORT |
|---|---|
| Condition | New Factory Sealed |
| Manufacturer | NVIDIA |
