HPE JL660-61101 Aruba 6300M 24Sr5 Cl6 POE+ 4Sfp56 Switch
Part Number:
JL660-61101
Got a Big Order or a Quick Question?
Let’s Connect—We Make Tech Buying Effortless.
Let’s Connect—We Make Tech Buying Effortless.
For Govt Institution credit terms or bulk order - Submit your detail below
Note: All heavy items above 20KG will be charged shipping
cost as per actual. Please contact us for a shipping quote before placing
order.
We accept Purchase Orders from Health & Educational
sector and all Government institutions including Councils.
Product Overview Device Type: Switch - 24 Ports - L3 - Managed - Stackable
Enclosure Type: Rack-mountable 1u
Subtype: Gigabit Ethernet
Ports: 24 X 1/2.5/5/10gbase-t + 4 X 1 Gigabit / 10 Gigabit / 25 Gigabit / 50 Gigabit Sfp56 (uplink / Stacking)
Power Over Ethernet (poe): Poe+
Poe Budget: 1440 W
Performance: Switching Capacity: 640 Gbps Throughput: 476 Mpps Latency (1 Gbps): 4.24 Μs Latency (10 Gbps): 1.5 Μs Latency (25 Gbps): 2.91 Μs Latency (50 Gbps): 3.49 Μs Stacking Bandwidth: 200 Gbps
Capacity: Switched Virtual Interfaces (svis): 1000 Ipv4 Host Table Capacity: 32000 Ipv6 Host Table Capacity: 32000 Ipv4 Routes (unicast): 64000 Ipv6 Routes (unicast): 32000 Ipv4 Routes (multicast): 8000 Ipv6 Routes (multicast): 8000 Igmp Groups: 8000 ¦ Mld Groups: 4000 ¦ Ipv4 Acl Entries (ingress): 5000 ¦ Ipv6 Acl Entries (ingress): 1250 Mac Acl Entries (ingress): 5000 Ipv4 Acl Entries (egress): 2000 Ipv6 Acl Entries (egress): 500 Mac Acl Entries (egress): 2000
Mac Address Table Size: 32000 Entries
Jumbo Frame Support: 9198 Bytes
Routing Protocol: Egp, Bgp-4, Igmpv2, Igmp, Vrrp, Ospfv2, Igmpv3, Ospfv3, Msdp, Static Ipv6 Routing, Ecmp, Mld, Bidirectional Forwarding Detection (bfd)
Remote Management Protocol: Rmon, Telnet, Snmp 3, Snmp 2c, Https, Tftp, Ssh, Cli, Xrmon, Sftp
Authentication Method: Radius, Tacacs+
Features: Dhcp Support, Arp Support, Vlan Support, Auto-uplink (auto Mdi/mdi-x), Igmp Snooping, High Availability, Per-vlan Spanning Tree (pvst), Multiple Spanning Tree Protocol (mstp) Support, Access Control List (acl) Support, Quality Of Service (qos), Jumbo Frames Support, Mld Snooping, Uni-directional Link Detection (udld), Rapid Per-vlan Spanning Tree Plus (pvrst+), Deficit Weighted Round Robin (dwrr), Lldp Support, Management Information Base (mib), Dhcp Protection, Dual Firmware Images, Multiple Vlan Registration Protocol (mvrp), Packet Storm Protection, Class Of Service (cos), Strict Priority (sp), Broadcast Storm Protection, Type Of Service (tos), Bridge Protocol Data Unit (bpdu), Virtual Extensible Lan (vxlan), Multicast Storm Protection, Network Timing Protocol (ntp), Ra Guard, Zero-touch Provisioning (ztp), Protocol Independent Multicast (pim), Vlan Tagging, Rapid Reconfiguration Of Spanning Tree (rstp), Ipv4 And Ipv6 Dual Stack, Ip Multicast, Front To Side Airflow, Aruba Virtual Switching Framework (vsf), Dynamic Ipv6 Lockdown, Nd Snooping, Unicast Storm Protection, Microsoft Network Load Balancer (nlb)
Compliant Standards: Ieee 802.1d, Ieee 802.1q, Ieee 802.1p, Ieee 802.3af, Ieee 802.3ad (lacp), Ieee 802.1w, Ieee 802.1x, Ieee 802.1s, Ieee 802.1v, Ieee 802.3at, Ieee 802.3bz, Ieee 802.3bt
Processor: 1 X Arm Cortex-a72: 1.78 Ghz
Ram: 8 Gb Ddr4 Sdram
Flash Memory: 32 Gb
Expansion / Connectivity :
Interfaces:
24 X 1/2.5/5/10gbase-t Rj-45 Poe+ - 60 W
4 X 1gbit/10gbit/25gbit/50gbit Sfp56
1 X Usb-c Console
1 X Management
1 X Usb Type A
Power :
Power Device: Internal Power Supply
Installed Qty: 0 (installed) / 2 (max) ( Minimum 1 Required)
80 Plus Certification: 80 Plus Silver
Energy Star Certified: Yes
Max Poe Power: 1440w
Supported Psu: Jl086a, Jl087a, Jl670a
Condition: New Retail Factory Sealed.
Availability: In Stock.
Our Warranty: 90 Days.
Mfg Warranty: Limited Lifetime.
HPE JL660-61101 Aruba 6300m 24-port HPE Smart Rate 1/2.5/5gbe Class 6 Poe+ And 4-port Sfp56 Switch ( No Psu Added -minimum 1 Required Max 2 Ordered Separately) :
Key Features :
Expansion / Connectivity :
Interfaces:
Power :
Condition: New Retail Factory Sealed.
Availability: In Stock.
Our Warranty: 90 Days.
Mfg Warranty: Limited Lifetime.
| Capacity | 24 PORT |
|---|---|
| Condition | New |
| Manufacturer | HPE |
