Delta Mini Relay I/O Hot‑Swap Module for UPS

PRODUCT OVERVIEW

GENERAL INFORMATION :
manufacturer : Delta Electronics
MANUFACTURER Part Number : 3915101864‑S
MANUFACTURER Website Address : WWW.DELTAELECTRONICS.COM

PRODUCT Name :
Delta Mini Relay I/O Hot‑Swap Module for UPS

PRODUCT DESCRIPTION :
Accessory Type : UPS Mini Relay I/O Card (Hot‑Swap)
Purpose : Expand UPS monitoring and control via relay contacts
Applicable UPS Series : Delta UPS models with Mini/Smart slot (e.g., N, R, RT, MX series)

FUNCTIONAL SPECIFICATIONS :
Output Contacts : 6 × programmable dry relay outputs (NO/NC) for UPS status signals
Input Contacts : 2 × configurable inputs for UPS control (e.g., shutdown, battery test)
Temperature Input : 1 × external temperature detection input (for sensor)
Configuration Interface : Integrated relay logic — settings via UPS configuration tools

ELECTRICAL SPECIFICATIONS :
Power Supply : 12 ± 3 V DC from UPS internal slot
Rated Power : ~3 W (typical)
Operating Voltage : 8–20 V DC range compatible (via UPS interface)

CONNECTIVITY & INTERFACES :
Relay Outputs : 6 dry contacts (programmable NO/NC)
Control Inputs : 2 inputs for UPS shutdown/battery test
Temperature Sensor Port : 1 input for external environmental sensor

PHYSICAL SPECIFICATIONS :
Dimensions : ~87 × 69 × 30 mm
Weight : ~0.07 kg (70 g)

ENVIRONMENTAL CONDITIONS :
Operating Temperature : ~0–50 °C
Humidity Range : ~10 – 80 % non‑condensing

COMPATIBILITY :
Compatible With : Delta UPS models with Mini/Smart card slot such as:
• N Series (from Rev.05)
• R Series
• RT Series (5–10 kVA models)
• MX Series

CONDITION : Brand New accessory
AVAILABILITY : In Stock (varies by seller)
OUR WARRANTY : Typically 1 Year (depending on seller)
