Delta Static Transfer Switch (STS) for Critical Power Systems

PRODUCT OVERVIEW

GENERAL INFORMATION :
manufacturer : Delta Electronics
MANUFACTURER Part Number : STS30002SR10035
MANUFACTURER Website Address : WWW.DELTAELECTRONICS.COM

PRODUCT Name :
Delta Static Transfer Switch (STS) for Critical Power Systems

POWER DESCRIPTION :
STS Type : Rack‑mount Static Transfer Switch
Rated Current : 30 A
Nominal Voltage : 200 / 208 / 220 / 230 / 240 Vac
Transfer Time : ~6–10 ms Automatic Transfer

INPUT SPECIFICATIONS :
Input Connections : (2) IEC309 / L6‑30P or equivalent independent inputs
Input Source Redundancy : Dual power source (redundant supply)

OUTPUT SPECIFICATIONS :
Output Connection : (1) IEC309 / L6‑30R
Load Protection : Automatic switching between sources to maintain UPS feed

BATTERY INFORMATION :
Battery : — (No internal battery; external UPS battery systems provide backup)
Backup : Not applicable — STS only switches between live AC sources to prevent power interruption

EXPANSION / CONNECTIVITY :
Communication Interface : SNMP (for remote monitoring)
Indicators : LED status panel

INTERFACES & PORTS :
1 X SNMP network interface
LED status indicators for mains/source status
(Exact port count depends on configuration)

DIMENSIONS & WEIGHT :
Dimensions (HxWxD) : ~43 × 440 × 385 mm
Weight : ~7.6 kg

ENVIRONMENTAL CONDITIONS :
Ambient Operating Temp. : 0–40 °C
Storage Temperature : –15–50 °C
Relative Humidity : 0–95 % non‑condensing
Audible Noise : < 40 dB

CONDITION : Brand New.
AVAILABILITY : In Stock (varies by seller).
OUR WARRANTY : Typically 1–3 Years (seller dependent)
