Cisco Catalyst 9300 48-port 1G SFP with modular uplinks, Meraki Advanced or Enterprise

PRODUCT OVERVIEW

GENERAL INFORMATION :

Manufacturer : Cisco
MANUFACTURER Part Number : C9300-48S-M
MANUFACTURER Website Address : WWW.CISCO.COM

PRODUCT Name : Cisco Catalyst 9300 Series (Meraki) Switch

POWER DESCRIPTION :

Power Supply : Default 715W AC Power Supply (Hot-swappable)
Redundant Power Supply : Supported (Dual PSU)
Power Consumption : ~88W (idle) to ~158W (max)

INPUT SPECIFICATIONS :

Input Voltage : 100–240 VAC
Input Frequency : 50–60 Hz

OUTPUT SPECIFICATIONS :

Switching Capacity : ~256 Gbps
Forwarding Rate : Up to ~190–547 Mpps (model/traffic dependent)

PORT INFORMATION :

Total Ports : 48 × 1G SFP Fiber Ports
Uplink Ports : Modular uplink (10G / 40G supported)
PoE Support : Not Supported

FEATURES :

Layer Support : Layer 3 Managed Switch
Stacking : StackWise-480 (up to ~480 Gbps stacking bandwidth)
Management : Cisco Meraki Cloud Dashboard
Security : Advanced Security (ACLs, segmentation, adaptive policy)
Automation : Cloud-managed, API & SD-Access ready

INTERFACES & PORTS :

1 × Dedicated Management Port
1 × USB Port
Stacking Ports (120G × 2)

DIMENSIONS & WEIGHT :

Dimensions (WxDxH) : ~445 × 449 × 44 mm
Weight : ~7.8 kg

ENVIRONMENTAL CONDITIONS :

Operating Temperature : -5 to 45 °C
Relative Humidity : 5–90 % non-condensing

CONDITION : Brand New.

AVAILABILITY : In Stock.

OUR WARRANTY : 1 Year.
