Cisco Business CBS350-24XS Managed Switch 24 Port 10G SFP+ 4x10GE Shared
Part Number:
CBS350-24XS
Got a Big Order or a Quick Question?
Let’s Connect—We Make Tech Buying Effortless.
Let’s Connect—We Make Tech Buying Effortless.
For Govt Institution credit terms or bulk order - Submit your detail below
Note: All heavy items above 20KG will be charged shipping
cost as per actual. Please contact us for a shipping quote before placing
order.
We accept Purchase Orders from Health & Educational
sector and all Government institutions including Councils.
Specifications
| Management features | |
|---|---|
| Reset button | Yes |
| Multicast support | Yes |
| ARP inspection | Yes |
| Switch type | Managed |
| Web-based management | Yes |
| System event log | Yes |
| Quality of Service (QoS) support | Yes |
| Switch layer | L3 |
| Configuring Location Settings (CLI) | Yes |
| Ports & interfaces | |
| Copper ethernet cabling technology | 10BASE-T, 10GBASE-T, 100BASE-TX |
| SFP+ module slots quantity | 24 |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | No |
| Console port | RJ-45 |
| 10G Ethernet (copper) ports quantity | 4 |
| Network | |
| IGMP snooping | Yes |
| GARP VLAN Registration Protocol (GVRP) | Yes |
| Cable types supported | Cat5e |
| Cable length detection | Yes |
| Active link detection | Yes |
| Copper ethernet cabling technology | 10BASE-T, 10GBASE-T, 100BASE-TX |
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3an, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Head-of-line (HOL) blocking | Yes |
| VLAN support | Yes |
| Spanning tree protocol | Yes |
| Rate limiting | Yes |
| Port mirroring | Yes |
| Number of VLANs | 4094 |
| Link aggregation | Yes |
| IP routing | Yes |
| Flow control support | Yes |
| Ethernet LAN data rates | 10,100,1000,10000 Mbit/s |
| Broadcast storm control | Yes |
| 10G support | Yes |
| Policy-based routing | Yes |
| VLAN mapping type | 1:1 VLAN mapping |
| Virtual LAN features | IP subnet–based VLAN, MAC address-based VLAN, Port-based VLAN, Private VLAN, Protocol-based VLAN, Stacked VLAN, Tagged VLAN, VLAN mapping, Voice VLAN |
| Virtual LAN features | |
| VLAN support | Yes |
| Number of VLANs | 4094 |
| VLAN mapping type | 1:1 VLAN mapping |
| Virtual LAN features | IP subnet–based VLAN, MAC address-based VLAN, Port-based VLAN, Private VLAN, Protocol-based VLAN, Stacked VLAN, Tagged VLAN, VLAN mapping, Voice VLAN |
| Data transmission | |
| Number of VLANs | 4094 |
| Multicast Listener Discovery (MLD) snooping | MLD v1/2 |
| Jumbo frames | 9000 |
| Number of static routes | 990 |
| Number of IP interfaces | 128 |
| Packet buffer memory | 3 MB |
| MAC address table | 16000 entries |
| Switching capacity | 480 Gbit/s |
| Number of queues | 8 |
| Jumbo frames support | Yes |
| Static route | Yes |
| Forwarding rate | 240 Mpps |
| Performance | |
| Packet buffer memory | 3 MB |
| Stackable | Yes |
| Physical stacking (units) | 4 |
| Processor frequency | 800 MHz |
| Noise level | 43 dB |
| Mean time between failures (MTBF) | 1356179 h |
| Internal memory | 512 MB |
| Flash memory | 256 MB |
| Firmware upgradeable | Yes |
| Built-in processor | Yes |
| Harmonized System (HS) code | 85176990 |
| Technical details | |
| Physical stacking (units) | 4 |
| Form factor | 1U |
| Product colour | Black, Grey |
| Stackable | Yes |
| Processor frequency | 800 MHz |
| Noise level | 43 dB |
| Mean time between failures (MTBF) | 1356179 h |
| Firmware upgradeable | Yes |
| Rack mounting | Yes |
| Built-in processor | Yes |
| Products per shipping (inner) case | 1 pc(s) |
| Sustainability compliance | Yes |
| Compliance certificates | CE |
| Security | |
| Loop protection | Yes |
| IP-MAC-Port binding | Yes |
| BPDU filtering/protection | Yes |
| Authentication | Guest VLAN, Port-based authentication |
| Access Control List (ACL) rules | 1024 |
| Security algorithms | 802.1x RADIUS, SSH, SSH-2, SSL/TLS |
| IGMP snooping | Yes |
| Access Control List (ACL) | Yes |
| Authentication type | IEEE 802.1x, RADIUS |
| DHCP features | DHCP relay, DHCP server, DHCP snooping, DHCPv6 client, DHCPv6 relay |
| Multicast features | |
| Multicast support | Yes |
| Multicast Listener Discovery (MLD) snooping | MLD v1/2 |
| Protocols | |
| Management protocols | SNMP v1/2c/3, Telnet, HTTP/HTTPS, SSH, RADIUS, BOOTP, SNTP |
| GARP VLAN Registration Protocol (GVRP) | Yes |
| Routing protocols | RIP-2 |
| Memory | |
| Packet buffer memory | 3 MB |
| Internal memory | 512 MB |
| Flash memory | 256 MB |
| Design | |
| Reset button | Yes |
| Country of origin | China |
| Form factor | 1U |
| Product colour | Black, Grey |
| Stackable | Yes |
| LED indicators | Activity, Link, PoE, Speed, System |
| Rack mounting | Yes |
| Number of fans | 4 fan(s) |
| Redundant fans support | Yes |
| Market segment | Business |
| Indication | |
| LED indicators | Activity, Link, PoE, Speed, System |
| Packaging content | |
| Packaging content | Switch, Power cord or adapter, Mounting hardware, and Quick Start Guide |
| Rack mount kit | Yes |
| Quick start guide | Yes |
| Cables included | AC |
| Mobile network | |
| GARP VLAN Registration Protocol (GVRP) | Yes |
| Power | |
| Power plug type | Type C |
| Power supply included | Yes |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power source | AC |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | No |
| Operational conditions | |
| Storage temperature (T-T) | -25 - 70 °C |
| Storage relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 0 - 50 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Heat dissipation | 133.1 BTU/h |
| Weight & dimensions | |
| Width | 350 mm |
| Depth | 439.9 mm |
| Height | 43.9 mm |
| Weight | 4.39 kg |
| Packaging data | |
| Rack mount kit | Yes |
| Quick start guide | Yes |
| Package width | 481.1 mm |
| Package depth | 572 mm |
| Package height | 95 mm |
| Package weight | 6.32 kg |
| Cables included | AC |
| Sustainability | |
| Sustainability compliance | Yes |
| Logistics data | |
| Products per master (outer) case | 1 pc(s) |
| Harmonized System (HS) code | 85176990 |
| Quantity per pack | 1 pc(s) |
| Other features | |
| Packaging content | Switch, Power cord or adapter, Mounting hardware, and Quick Start Guide |
| Ethernet LAN data rates | 10,100,1000,10000 Mbit/s |
| Country of origin | China |
| Condition | New |
|---|---|
| Manufacturer | CISCO |
