Cisco C9300X-48TX-A Catalyst 48-Port 10G/Multi-G Switch
Part Number:
C9300X-48TX-A
Got a Big Order or a Quick Question?
Let’s Connect—We Make Tech Buying Effortless.
Let’s Connect—We Make Tech Buying Effortless.
For Govt Institution credit terms or bulk order - Submit your detail below
Note: All heavy items above 20KG will be charged shipping
cost as per actual. Please contact us for a shipping quote before placing
order.
We accept Purchase Orders from Health & Educational
sector and all Government institutions including Councils.
Product Overview Product Description: CISCO Catalyst 9300x - Network Advantage - Switch - 48 Ports - Managed - Rack-mountable
Device Type: Switch - 48 Ports - L3 - Managed - Stackable
Enclosure Type: Rack-mountable
Subtype: 10 Gigabit Ethernet
Ports: 48 X 100/1000/2.5g/5g/10gbase-t
Performance: Switching Capacity: 2000 Gbps ¦ Switching Capacity With Stacking: 3000 Gbps ¦ Forwarding Rate: 1488 Mpps ¦ Forwarding Rate With Stacking: 2232 Mpps
Capacity: Ipv4 Routing Table Entries: 39000 ¦ Multicast Routes: 8000 ¦ Qos Scale Entries: 4000 ¦ Acl Scale Entries: 8000 ¦ Ipv6 Routing Table Entries: 19500 ¦ Packet Buffer Size: 16 Mb ¦ Fnf Entries: 64000 ¦ Vlan Ids: 4094 ¦ Switched Virtual Interfaces (svis): 1000
Mac Address Table Size: 32000 Entries
Jumbo Frame Support: 9198 Bytes
Routing Protocol: Mstp, Static Ip Routing, Rip-1, Rip-2, Ripng, Pim-sm, Pim-ssm, Gre, Rip, Policy-based Routing (pbr), Stp, Vrrp, Lisp
Remote Management Protocol: Netconf, Restconf, Yang, Http, Cli, Grpc, Rmon 1, Rmon 2, Snmp 1, Snmp 2c, Snmp 3
Features: CISCO Uadp 2.0, Qos, Sudi, CISCO Stackwise Technology, Ztp, Preboot Execution Environment, CISCO Stackwise-1t Technology, Rapid Pvst+, Fnf, Dscp Support, Srr, Cir, Mdns, Eee, Blue Beacon Led, Evpn, Pim, Vpn Support, Vpls, Eompls, Cdp, Fhs, 802.1x Authentication, Rspan, Lacp Support, Full Duplex Mode, Pvlan Support, Copp, Span
Compliant Standard: Ieee 802.1ba, Ieee 1588v2, Ieee 802.1ae, Ieee 802.1s, Ieee 802.1w, Ieee 802.1p, Ieee 802.1x, Ieee 802.3ad (lacp), Ieee 802.3af, Ieee 802.3at, Ieee 802.3x, Ieee 802.1d, Ieee 802.1q, Ieee 802.3, Ieee 802.3u, Ieee 802.3ab, Ieee 802.3z, Ieee 802.3bz, Ieee 802.3an
Power: Ac 100-240 V (50 - 60 Hz)
Power Redundancy: Optional
Dimensions (wxdxh): 17.5 In X 22 In X 1.7 In
Weight: 14.59 Lbs
Expansion / Connectivity
Interfaces: 48 X 100/1000/2.5g/5g/10gbase-t Rj-45 ¦ 1 X Usb 2.0
Expansion Slots: 1 (total) / 1 (free) X Expansion Slot
Power
Power Device: Internal Power Supply - Hot-plug
Installed Qty: 1
Max Supported Qty: 2
Power Provided: 715 Watt
Condition: New Factory Sealed
Availability: Call
Our Warranty: 90 Days
CISCO C9300X-48TX-A Catalyst 48-port 10g/multi-g Switch
Primary Information
Expansion / Connectivity
Power
Condition: New Factory Sealed
Availability: Call
Our Warranty: 90 Days
| Capacity | 48 PORT |
|---|---|
| Condition | New Factory Sealed |
| Manufacturer | CISCO |
