Cisco C9300LM-48T-4Y-A Catalyst 9300LM Fixed Uplink Switch
Part Number:
C9300LM-48T-4Y-A
Got a Big Order or a Quick Question?
Let’s Connect—We Make Tech Buying Effortless.
Let’s Connect—We Make Tech Buying Effortless.
For Govt Institution credit terms or bulk order - Submit your detail below
Note: All heavy items above 20KG will be charged shipping
cost as per actual. Please contact us for a shipping quote before placing
order.
We accept Purchase Orders from Health & Educational
sector and all Government institutions including Councils.
Product Overview Device Type : Switch - 48 Ports - L3 - Managed - Stackable
Enclosure Type : Rack-mountable
Subtype : Gigabit Ethernet
Ports : 48 X 10/100/1000 + 4 X 25 Gigabit Sfp (uplink)
Performance : Stacking Bandwidth: 320 Gbps ¦ Switching Capacity: 296 Gbps ¦ Switching Capacity With Stacking: 616 Gbps ¦ Forwarding Rate: 220.22 Mpps ¦ Forwarding Rate With Stacking: 458.3 Mpps
Capacity : Ipv4 Routes: 32000 ¦ Ipv6 Routes: 16000 ¦ Multicast Scale: 8000 ¦ Qos Scale Entries: 5120 ¦ Acl Scale Entries: 5120 ¦ Buffer Capacity (mb): 16 ¦ Fnf Entries: 64000 ¦ Vlan Ids: 4094 ¦ Switched Virtual Interfaces (svis): 1000 ¦ Routed Ports: 416 ¦ Ospf Routes: 1000
Mac Address Table Size : 32000 Entries
Jumbo Frame Support : 9198 Bytes
Max Units In A Stack : 8
Routing Protocol : Ospf, Rip-1, Rip-2, Eigrp, Vrrp, Pim-sm, Ospfv3, Pim-ssm, Policy-based Routing (pbr), Ripng, Mstp
Remote Management Protocol : Snmp 1, Rmon 1, Rmon 2, Snmp 3, Snmp 2c, Cli, Netconf, Restconf, Grpc, Ipv4, Ipv6, Yang
Encryption Algorithm : 128-bit Aes, 256-bit Aes
Features : Access Control List (acl) Support, Quality Of Service (qos), CISCO Stackwise Technology, Rapid Per-vlan Spanning Tree Plus (pvrst+), Shaped Round Robin (srr), Remote Switch Port Analyzer (rspan), Netflow, Class Of Service (cos), Flexible Netflow (fnf), Diffserv Code Point (dscp) Support, Hot Swappable 3 Fans, Built-in Asic, Control Plane Protection (copp), Software Defined Networking (sdn), Blue Beacon Led, Zero-touch Provisioning (ztp), Secure Boot, Energy-efficient Ethernet (eee), Switched Port Analyzer (span), Protocol Independent Multicast (pim), First Hop Security (fhs), Pvlan Support, Committed Information Rate (cir), Media Access Control Security (macsec), CISCO Ip Service-level Agreement (ip Sla), CISCO Trust Anchor Module, CISCO Unified Access Data Plane (uadp) 2.0, CISCO Stackwise-320 Technology, CISCO Discovery Protocol (cdp), Preboot Execution Environment
Compliant Standards : Ieee 802.3, Ieee 802.3u, Ieee 802.3z, Ieee 802.1d, Ieee 802.1q, Ieee 802.3ab, Ieee 802.1p, Ieee 802.3af, Ieee 802.3x, Ieee 802.3ad (lacp), Ieee 802.1w, Ieee 802.1x, Ieee 802.3ae, Ieee 802.1s, Ieee 802.1ae, Ieee 802.3an, Ieee 802.3at, Ieee 1588v2, Ieee 802.1ba, Ieee 802.3bz, Ieee 802.3bt, Wi-fi Certified 6
Ram : 8 Gb
Flash Memory : 16 Gb
Status Indicators : Status
Expansion / Connectivity :
Interfaces :
48 X 1000base-t Rj-45
4 X 25gbase-x Sfp Uplink
Network Stack Device
1 X Management (lan) Rj-45
1 X Console
1 X Usb 2.0
Power :
Power Device : Internal Power Supply - Hot-plug
Installed Qty : 1
Max Supported Qty : 2
Power Redundancy : Optional
Power Provided : 600 Watt
Voltage Required : Ac 100-240 V (50 - 60 Hz)
Condition : Refurbished
Availability : In Stock
Our Warranty : 90 Days
CISCO C9300LM-48T-4Y-A Catalyst 9300l Mini - Network Advantage - Switch - L3 - Managed - 48 X 10/100/1000 + 4 X 25 Gigabit Sfp (uplink) - Rack-mountable.
Key Features :
Expansion / Connectivity :
Interfaces :
Power :
Condition : Refurbished
Availability : In Stock
Our Warranty : 90 Days
| Capacity | 48 PORT |
|---|---|
| Condition | Refurbished |
| Manufacturer | CISCO |
