Cisco C9200L-48PL-4G-E Catalyst 9200L 48P Partial PoE+ 4x1G Uplink Switch
Part Number:
C9200L-48PL-4G-E
Got a Big Order or a Quick Question?
Let’s Connect—We Make Tech Buying Effortless.
Let’s Connect—We Make Tech Buying Effortless.
For Govt Institution credit terms or bulk order - Submit your detail below
Note: All heavy items above 20KG will be charged shipping
cost as per actual. Please contact us for a shipping quote before placing
order.
We accept Purchase Orders from Health & Educational
sector and all Government institutions including Councils.
Product Overview Device Type : Switch - 48 Ports - L3 - Stackable
Enclosure Type : Rack-mountable
Subtype : Gigabit Ethernet
Ports : 48 X 10/100/1000 (poe+) + 4 X Gigabit Sfp (uplink)
Power Over Ethernet (poe) : Poe+
Poe Budget : 370 W
Performance : Stacking Bandwidth: 80 Gbps ¦ Switching Capacity: 104 Gbps ¦ Forwarding Rate: 77.38 Mpps ¦ Switching Capacity With Stacking: 184 Gbps ¦ Forwarding Rate With Stacking: 137 Mpps
Capacity : Virtual Networks: 1 ¦ Ipv4 Routes: 11000 ¦ Ipv4 Routing Table Entries: 3000 ¦ Ipv6 Routing Table Entries: 1500 ¦ Multicast Scale: 1000 ¦ Acl Scale Entries: 1500 ¦ Fnf Entries: 16000 ¦ Vlans Supported: 1024 ¦ Switched Virtual Interfaces (svis): 512 ¦ Qos Hardware Queues Per Port: 8
Mac Address Table Size : 16000 Entries
Jumbo Frame Support : 9198 Bytes
Routing Protocol : Ospf, Rip-1, Rip-2, Eigrp, Vrrp, Pim-sm, Eigrp For Ipv6, Pim-ssm, Policy-based Routing (pbr), Ripng, Mstp
Remote Management Protocol : Snmp 1, Rmon 1, Rmon 2, Snmp 3, Snmp 2c, Cli, Netconf, Restconf
Encryption Algorithm : 128-bit Aes
Features : Quality Of Service (qos), CISCO Stackwise Technology, Rapid Per-vlan Spanning Tree Plus (pvrst+), Shaped Round Robin (srr), Pxe Support, Remote Switch Port Analyzer (rspan), Netflow, Energy Efficient Ethernet, Management Information Base (mib), Class Of Service (cos), Flexible Netflow (fnf), 802.1x Authentication, Diffserv Code Point (dscp) Support, Macsec Support, 6mb Packet Buffer, Control Plane Protection (copp), Switched Port Analyzer (span), Embedded Event Manager (eem), Protocol Independent Multicast (pim), First Hop Security (fhs), Pvlan Support, Committed Information Rate (cir)
Compliant Standards : Ieee 802.3, Ieee 802.3u, Ieee 802.3z, Ieee 802.1d, Ieee 802.1q, Ieee 802.3ab, Ieee 802.1p, Ieee 802.3x, Ieee 802.3ad (lacp), Ieee 802.1w, Ieee 802.1x, Ieee 802.1s
Ram : 2 Gb
Flash Memory : 4 Gb
Built-in Devices : Rfid Tag
Expansion / Connectivity :
Interfaces :
48 X 1000base-t Rj-45 Partial Poe+
4 X 1000base-x Sfp Uplink
1 X Network Stack Device
1 X Management (lan) Rj-45
1 X Console Rj-45
Power :
Power Device : Internal Power Supply - Hot-plug
Max Supported Qty : 2
Power Redundancy : Optional
Voltage Required : Ac 100-240 V (50 - 60 Hz)
Condition : New Factory Sealed
Availability : In Stock
Our Warranty : 90 Days
CISCO C9200L-48PL-4G-E Catalyst 9200l - Network Essentials - Switch - 48 Ports - Partial Poe+ - Rack-mountable :
Key Features :
Expansion / Connectivity :
Interfaces :
Power :
Condition : New Factory Sealed
Availability : In Stock
Our Warranty : 90 Days
| Capacity | 48 PORT |
|---|---|
| Condition | New Factory Sealed |
| Manufacturer | CISCO |
