HPE AP-505H-US Aruba Networking Dual Radio 802.11ax 2x2 1+4 Ethernet PSE USB Hospitality AP
Part Number:
AP-505H-US
Got a Big Order or a Quick Question?
Let’s Connect—We Make Tech Buying Effortless.
Let’s Connect—We Make Tech Buying Effortless.
For Govt Institution credit terms or bulk order - Submit your detail below
Note: All heavy items above 20KG will be charged shipping
cost as per actual. Please contact us for a shipping quote before placing
order.
We accept Purchase Orders from Health & Educational
sector and all Government institutions including Councils.
Product Overview
Specifications :
Certifications
Bluetooth Sig
Ethernet Alliance (poe)
Wi-fi Alliance:
Wi-fi Certified A, B, G, N, Ac
Wi-fi Certified 6 (ax)
Wpa, Wpa2 And Wpa3- Enterprise With Cnsa Option, Personal (sae), Enhanced Open (owe)
Wmm, Wmm-ps, Wi-fi Agile Multiband
Passpoint (release 2)
Wi-fi Certified Location (HPE Ap-505h Only)
Regulatory
Fcc/ised
Ce Marked
Red Directive 2014/53/eu
Emc Directive 2014/30/eu
Low Voltage Directive 2014/35/eu
Ul/iec/en 62368-1
En 60601-1-1, En60601-1-2
Wi-fi Antenna
Two Integrated Semi-directional Antennas For 2x2 Mimo With Peak Single Antenna Gain Of 5.2dbi In 2.4ghz And 5.4dbi In 5ghz. Built-in Antennas Are Optimized For Vertical Wall Or Desk Mounted Orientation Of The Ap.
Combining The Patterns Of Each Of The Antennas Of The Mimo Radios, The Peak Gain Of The Combined, Average Pattern Is 3.3dbi In 2.4ghz And 2.9dbi In 5ghz.
Ports
(1) HPE Smart Rate Rj-45 Port, Auto-sensing Link Speed (100/1000/2500base-t) And Mdi/mdx. 2.5 Gbps Speed Complies With Nbase-t And 802.3bz Specifications
(4) 10/100/1000base-t (rj-45) Ports, Auto-sensing Link Speed And Mdi/mdx
Power Consumption 50w Max
Radio Coverage
5 Ghz Radio: Two Spatial Stream (su/mu) Mimo For Up To 1.2 Gbps Wireless Data Rate (he80)
2.4 Ghz Radio: Two Spatial Stream (su/mu) Mimo For Up To 287 Mbps Wireless Data Rate (he20)
Weight 360 Gm (0.8 Lb)
Dimensions 150 X 86 X 47 Mm (5.9 X 3.4 X 1.9 In)
Condition: New Factory Sealed.
Availability: In Stock.
Serversupply Warranty: 90 Days.
HPE AP-505H-US Aruba Networking Dual Radio 802.11ax 2x2 1+4 Ethernet Pse Usb Hospitality Ap.
Specifications :
Certifications
Regulatory
Wi-fi Antenna
Ports
Power Consumption 50w Max
Radio Coverage
Weight 360 Gm (0.8 Lb)
Dimensions 150 X 86 X 47 Mm (5.9 X 3.4 X 1.9 In)
Condition: New Factory Sealed.
Availability: In Stock.
Serversupply Warranty: 90 Days.
| Capacity | WIRELESS 1.2GBPS |
|---|---|
| Condition | New Factory Sealed |
| Manufacturer | HPE |
