Supermicro AOC-A25G-M2SM 2-port 25 Gigabit Ethernet Adapter with a 0.5U height Bracket
Part Number:
AOC-A25G-M2SM
Got a Big Order or a Quick Question?
Let’s Connect—We Make Tech Buying Effortless.
Let’s Connect—We Make Tech Buying Effortless.
For Govt Institution credit terms or bulk order - Submit your detail below
Note: All heavy items above 20KG will be charged shipping
cost as per actual. Please contact us for a shipping quote before placing
order.
We accept Purchase Orders from Health & Educational
sector and all Government institutions including Councils.
Product Overview Advanced I/o Module (aiom) Form Factor
Mellanox Connectx-6 Lx 25gbe Controller
Support For 25gbe And 10gbe Speed
Dual Sfp28 Connectors
Rdma Over Converged Ethernet
Vxlan, Nvgre And Geneve
Asset Management Features With Thermal Sensor
Network Controller Sideband Interface (nc-si) For Remote Management
Specifications
General
Advanced I/o Module (aiom) Form Factor
Mellanox Connectx-6 Lx 25gbe Controller
Dual Sfp28 Port
Storage Accelerations
Nvme Over Fabric Offloads For Target
Storage Protocols: Iser, Nfsordma,
Smb Direct, Nvme-of, And More
Rdma Over Converged Ethernet
Roce V1/v2
Zero-touch Roce: No Ecn, No Pfc
Roce Over Overlay Networks
Ipsec Over Roce
Selective Repeat
Gpudirect®
Dynamically Connected Transport (dct)
Management And Control
Smbus 2.0
Network Controller Sideband Interface (nc-si)
Nc-si, Mctp Over Smbus And Mctp Over Pcie - Baseboard Management Controller Interface
Pldm For Monitor And Control Dsp0248
Pldm For Firmware Update Dsp026
Remote Boot
Remote Boot Over Ethernet
Remote Boot Over Iscsi
Uefi Support For X86 And Arm Servers
Pxe Boot
Standards:
Ieee 802.3ae 10 Gigabit Ethernet
Ieee 802.3by 25g Supporting All Fec Modes
Ieee 802.3ad, 802.1ax Link Aggregation
Ieee 802.3az Energy Efficient Ethernet (supports Only “fast-wake” Mode)
Ieee 802.3ap Based Auto-negotiation And Kr Startup
Ieee 802.1q, 802.1p Vlan Tags And Priority
Ieee 802.1qaz (ets)
Ieee 802.1qbb (pfc)
Ieee 802.1qbg
Ieee 1588v2
Ieee 1149.1 And Ieee 1149.6 Jtag
Pci-e 3.0 And 4.0
Power Consumption:
Maximum: 15w
Operating Conditions:
Storage Temperature: -40°c To 70°c (-40°f To 158°f)
Storage Humidity: 90% Non-condensing Relative Humidity At 35°c
Physical Dimensions:
Card Pcb Dimensions: 76mm X 115mm (w X D)
Condition: Refurbished.
Availability: In Stock.
Our Warranty: 90 Days.
SUPERMICRO AOC-A25G-M2SM 2-port 25 Gigabit Ethernet Adapter With A 0.5u Height Bracket
Overview SUPERMICRO Advanced I/o Modules (aiom) Are The Latest Form Factor Designed To Provide A Wide Range Of Networking Options As Well As Other I/o Technologies. The AOC-A25G-M2SM Is One Of The Most Feature Rich And Low Power Consumption 25gbe Controllers In The Market. Based On The Mellanox Connectx-6 Lx Controller With Features Such As Vxlan, Nvgre, Rdma, And Others, It Provides Unparalleled Density, Performance, And Functionality. The SUPERMICRO® AOC-A25G-M2SM Is The Most Versatile 25gbe Controller In The Market With The Best Total Cost Of Ownership For 25gbe Deployments In Cloud, Telco, And Enterprise Data Centers.
Key Features:
Specifications
General
Storage Accelerations
Rdma Over Converged Ethernet
Management And Control
Remote Boot
Standards:
Power Consumption:
Operating Conditions:
Physical Dimensions:
Condition: Refurbished.
Availability: In Stock.
Our Warranty: 90 Days.
| Capacity | 2 PORT |
|---|---|
| Condition | Refurbished |
| Manufacturer | SUPERMICRO |
