NVIDIA 980-9I30H-F4NM00 Twin Port Transceiver 800Gbps 2x400GbE OSFP 2xMPO12 APC 1310nm SMF Up to 100m Finned
Part Number:
980-9I30H-F4NM00
Got a Big Order or a Quick Question?
Let’s Connect—We Make Tech Buying Effortless.
Let’s Connect—We Make Tech Buying Effortless.
For Govt Institution credit terms or bulk order - Submit your detail below
Note: All heavy items above 20KG will be charged shipping
cost as per actual. Please contact us for a shipping quote before placing
order.
We accept Purchase Orders from Health & Educational
sector and all Government institutions including Councils.
Product Overview The NVIDIA Mms4x00-ns-t Is An Ethernet 800gb/s 2x400gb/s Twin-port Osfp, 2xdr4 Single Mode, Parallel, 8-channel Transceiver Using Two, 4-channel Mpo-12/apc Optical Connectors At 400gb/s Each. The Parallel Single Mode, Datacenter Reach 8-channel (2xdr4) Design Uses 100g-pam4 Modulation, And Has A Maximum Fiber Reach Of 100-meters Using 8 Single Mode Fibers. The 100-meter Length Assumes Two Optical Patch Panels In The Link.
The Twin-port 2xdr4 Transceiver Is A Key NVIDIA Innovation With Two Internal Transceiver Engines Enabling 128-ports Of 400gb/s In A 64 Cages Spectrum-4 Switches.
The Spectrum-4 Switches Require Finned-top Osfp Shells For Extra Transceiver Cooling. The Main Application For Mms4x00-ns-t Is Linking Two Switches Together With Up To 100-meters.
The Transceiver Combinations Guarantee Optimal Operation In NVIDIA End-to-end Ethernet Systems And A Rigorous Production Tested To Ensure The Best Out-of-the-box Installation Experience, Performance, And Durability
Key Features
800g 2xdr4 Single Mode Transceiver
8-channels Of 100g-pam4 Electrical Modulation
Two Mpo-12/apc Optical Connectors
Two Ports Of 4-channel 100g-pam4 Optical Modulation
Supports Two Straight 400gb/s Or Two 1:2 Splitter Fiber Cables For 200gb/s
Finned-top Osfp For Air-cooled Switches
1310nm Eml Laser
Maximum Reach: 100m
17-watts Max Power
Single 3.3v Power Supply
Class 1 Laser Safety
Hot Pluggable, Rohs Compliant
Osfpmsa.org Compliant
Cmis 4.0 Compliant
Case Temperature Range Of 0°c To +70°c
Applications
Used In Spectrum-4 Air-cooled Switches
Condition: New Factory Sealed.
Availability: In Stock.
Our Warranty: 90 Days.
NVIDIA 980-9I30H-F4NM00 Twin Port Transceiver 800gbps 2x400gbe Osfp 2xmpo12 Apc 1310nm Smf Up To 100m Finned
Specifications
Overview
Key Features
Applications
Condition: New Factory Sealed.
Availability: In Stock.
Our Warranty: 90 Days.
| Capacity | 800 GIGABIT |
|---|---|
| Condition | New Factory Sealed |
| Manufacturer | NVIDIA |
