Juniper Networks 740-080490 40GBASE-BXSR OM3 100m 850nm 70C
Part Number:
740-080490
Got a Big Order or a Quick Question?
Let’s Connect—We Make Tech Buying Effortless.
Let’s Connect—We Make Tech Buying Effortless.
For Govt Institution credit terms or bulk order - Submit your detail below
Note: All heavy items above 20KG will be charged shipping
cost as per actual. Please contact us for a shipping quote before placing
order.
We accept Purchase Orders from Health & Educational
sector and all Government institutions including Councils.
Product Overview Tx Power
Rx Power
Bias Current
Case Temperature
Power Supply Voltage
Signaling Rate, Each Lane 20.625gbd
Transmitter Wavelengths (range)
Wavelength 1: 832nm To 868nm
Wavelength 2: 882nm To 918nm
Receive Lane Wavelengths (range)
Wavelength 1: 832nm To 868nm
Wavelength 2: 882nm To 918nm
Transmitter Rms Spectral Width (maximum) 0.59 Nm
Transmitter Output Power, Each Lane (minimum) -4.0 Dbm
Transmitter Output Power, Each Lane (maximum) 5.0 Dbm
Receiver Input Power, Each Lane (maximum) +5.0 Dbm
Receiver Sensitivity (oma), Each Lane (maximum)
For Center Wavelength 1 @ 850nm: -7.1 Dbm
For Center Wavelength 2 @ 900nm: -7.7 Dbm
Stressed Receiver Sensitivity (oma) Each Lane (maximum) -3.83 Dbm
Cable Type Mmf
Core Size/cladding 50/125 Micrometer
Fiber Grade Om3 , Om4
Effective Modal Bandwidth 2000 Mhz X Km(om3), 4700 Mhz X Km(om4)
Distance 100 M(om3), 150 M(om4).
Maximum Power Consumption (w) 3.5 W
Operating Temperature (range) 0° C To 70° C
Storage Temperature –40° C To 85° C
Typical Weight & Dimensions
Typically Weight: 100 Grams
Dimensions(h X W X D): 13.5 X 18.4 X 72.4 Mm
Condition: New.
Availability: In Stock.
Our Warranty: 90 Days.
Juniper Networks 740-080490 40gbase-bxsr Om3 100m 850nm 70c
Specifications
Speed 40 Gigabit Ethernet
Breakout Capable No
Transceiver Type Qsfp+
Product Type Optical Transceiver
Connector Duplex Lc
Monitoring Available Yes
Digital Optical Monitoring Yes
Additional Information The 40-gbps Bxsr Transceiver Uses Two Bi-directional Transmitter/receivers, Each Supporting 20 Gbps, Over Two Multi-mode Fiber Strands (duplex Multi-mode Cable). The Left Lc Receptacle Transmits At A Nominal Wavelengths Of 850 Nm, And Receives At A Nominal Wavelength Of 900 Nm. The Right Lc Receptacle Transmits At A Nominal Wavelengths Of 900 Nm, And Receives At A Nominal Wavelength Of 850 Nm. Standard Om3/om4 Mmf Patch Cords Can Be Used To Interconnect 40-gbps Bxsr Transceiver.
Standards Compliance (ethernet/otn Standard, For E.g. 100gbase-lr4) Compliant To Ieee802.3-2015 Xlppi Electrical Specification
Msa Compliance (sff, For E.g. Sff-8665) Sff-8436
Optic Type (commercial Vs Service Provider Grade) Mmf
Digital Diagnostic Monitoring
Signaling Rate, Each Lane 20.625gbd
Transmitter Wavelengths (range)
Receive Lane Wavelengths (range)
Transmitter Rms Spectral Width (maximum) 0.59 Nm
Transmitter Output Power, Each Lane (minimum) -4.0 Dbm
Transmitter Output Power, Each Lane (maximum) 5.0 Dbm
Receiver Input Power, Each Lane (maximum) +5.0 Dbm
Receiver Sensitivity (oma), Each Lane (maximum)
Stressed Receiver Sensitivity (oma) Each Lane (maximum) -3.83 Dbm
Cable Type Mmf
Core Size/cladding 50/125 Micrometer
Fiber Grade Om3 , Om4
Effective Modal Bandwidth 2000 Mhz X Km(om3), 4700 Mhz X Km(om4)
Distance 100 M(om3), 150 M(om4).
Maximum Power Consumption (w) 3.5 W
Operating Temperature (range) 0° C To 70° C
Storage Temperature –40° C To 85° C
Typical Weight & Dimensions
Condition: New.
Availability: In Stock.
Our Warranty: 90 Days.
| Capacity | 40 GIGABIT |
|---|---|
| Condition | New |
| Manufacturer | JUNIPER NETWORKS |
