Juniper Networks 740-061405 QSFP-28 100G-SR4 Transceiver
Part Number:
740-061405
Got a Big Order or a Quick Question?
Let’s Connect—We Make Tech Buying Effortless.
Let’s Connect—We Make Tech Buying Effortless.
For Govt Institution credit terms or bulk order - Submit your detail below
Note: All heavy items above 20KG will be charged shipping
cost as per actual. Please contact us for a shipping quote before placing
order.
We accept Purchase Orders from Health & Educational
sector and all Government institutions including Councils.
Product Overview
Juniper Networks 740-061405 Qsfp-28 100g-sr4 Transceiver
Specifications
Speed 4 X 25 Gigabit Ethernet, 100 Gigabit Ethernet
Breakout Capable Yes
Transceiver Type Qsfp28
Product Type Optical Transceiver
Connector Mpo-12
Monitoring Available Yes
Digital Optical Monitoring Yes
Standards Compliance (ethernet/otn Standard, For E.g. 100gbase-lr4) Ieee 802.3ba-2010
Diagnostic Support Yes
Signaling Rate, Each Lane 25.78125 Gbd +/- 100 Ppm
Transmitter Wavelengths (range) 840 Nm Through 860 Nm
Receive Lane Wavelengths (range) 840 Nm Through 860 Nm
Transmitter Output Power, Each Lane (minimum) –8.4 Dbm
Transmitter Output Power, Each Lane (maximum) 2.4 Dbm
Receiver Input Power, Each Lane (minimum) –10.3 Dbm
Receiver Input Power, Each Lane (maximum) 2.4 Dbm
Cable Type Smf
Core Size/cladding 50/125 Micrometer
Fiber Grade Om3, Om4
Distance 70 Km(om3), 100 M(om4)
Effective Modal Bandwidth 2000 Mhz X Km(om3), 4700 Mhz X Km(om4)
Maximum Power Consumption (w) 3.5 W
Operating Temperature (range) 0° C To 70° C
Storage Temperature –40° C To 85° C
Condition: In Stock.
Availability: In Stock.
Our Warranty: 90 Days.
| Capacity | 100 GIGABIT |
|---|---|
| Condition | New |
| Manufacturer | JUNIPER NETWORKS |
