Dell 210-ABOF Networking N3024P 24P 1Gbe L3 2P 10Gbe Poe+ Switch
Part Number:
210-ABOF
Got a Big Order or a Quick Question?
Let’s Connect—We Make Tech Buying Effortless.
Let’s Connect—We Make Tech Buying Effortless.
For Govt Institution credit terms or bulk order - Submit your detail below
Note: All heavy items above 20KG will be charged shipping
cost as per actual. Please contact us for a shipping quote before placing
order.
We accept Purchase Orders from Health & Educational
sector and all Government institutions including Councils.
Product Overview Device Type : Switch - 24 Ports - L3 - Managed - Stackable
Enclosure Type : Rack-mountable 1u
Subtype : Gigabit Ethernet
Ports : 24 X 10/100/1000 + 2 X 10 Gigabit Sfp+ + 2 X Combo Gigabit Sfp
Power Over Ethernet (poe) : Poe+
Performance : Switching Fabric Bandwidth: 212 Gbps , Forwarding Performance: 158 Mpps , Stacking Bandwidth: 84 Gbps
Capacity : Mac Addresses: 16384 , Ipv4 Routes (static): 1024 , Ipv6 Routes (static): 1024 , Ipv4 Routes (dynamic): 8160 , Ipv6 Routes (dynamic): 4096 , Maximum Member Ports Per Lag: 8 , Maximum Dynamic Ports Per Switch Stack: 144 , Lag Groups: 128 , Ospf Routes: 8160 , Rip Routes: 512 , Ecmp Next Hops Per Route: 4 , Ecmp Groups: 64 , Vlan Routing Interfaces: 128 , Vlans Supported: 4094 , Multicast Entries (ipv4): 512 , Multicast Entries (ipv6): 256 , Arp Entries: 6144 , Ndp Entries: 400 , Acl: 100 , Maximum Rules Per Acl: 1023 , Max Acl Rules System-wide: 4096 , Maximum Acl Rules Per Interface (ipv4) Egress Rules: 1024 , Maximum Acl Rules Per Interface (ipv4) Ingress Rules: 3072 , Maximum Acl Rules Per Interface (ipv6) Egress Rules: 512 , Maximum Acl Rules Per Interface (ipv6) Ingress Rules: 1021 , Maximum Vlan Interfaces With Acls Applied: 24
Mac Address Table Size : 16k Entries
Routing Protocol : Ospf, Rip-1, Rip-2, Igmpv2, Igmp, Vrrp, Pim-sm, Pim-dm, Igmpv3, Ospfv3, Mldv2, Mld
Remote Management Protocol : Snmp 2, Snmp, Rmon, Http, Ssh
Encryption Algorithm : Md5, Aes, Ssl, Tls
Authentication Method : Secure Shell (ssh), Radius, Tacacs+
Features : Layer 3 Switching, Layer 2 Switching, Mdi/mdi-x Switch, Auto-negotiation, Port Mirroring, Stackable, Broadcast Storm Control, Multiple Spanning Tree Protocol (mstp) Support, Per-vlan Rapid Spanning Tree (pvrst), Energy Efficient Ethernet, Dynamic Vlan Support (gvrp), Dual Firmware Images, Network Access Control (nac), Tagged Vlan, Redundant Fans, Protocol-based Vlans Support
Compliant Standards : Ieee 802.2, Ieee 802.3, Ieee 802.3u, Ieee 802.3z, Ieee 802.1d, Ieee 802.1q, Ieee 802.3ab, Ieee 802.1p, Ieee 802.3x, Ieee 802.3ad (lacp), Ieee 802.1w, Ieee 802.1x, Ieee 802.3ae, Ieee 802.3ac, Ieee 802.1s, Ieee 802.1v, Ieee 802.1ag, Ieee 802.1ab (lldp), Ieee 802.3az
Ram : 1 Gb
Flash Memory : 256 Mb
Expansion / Connectivity :
Interfaces : 24 X Gigabit Lan - Rj-45 , 2 X 10gbit Lan - Sfp+ , 2 X Gigabit Lan , 1 X Serial (rs-232) - Rj-45 - Management , 1 X Usb - Type A , 2 X Network Stack Device
Expansion Slots : 1 (total) / 1 (free) X Expansion Slot
Power :
Power Device : Internal Power Supply - Hot-plug
Installed Qty : 1 (installed) / 2 (max)
Power Redundancy : Optional
Power Provided : 715 Watt
Condition : Refurbished.
Availability : In Stock.
Our Warranty : 90 Days.
DELL 210-ABOF Networking N3024p - Switch - 24 Ports - Managed - Rack-mountable.
Key Features :
Expansion / Connectivity :
Power :
Condition : Refurbished.
Availability : In Stock.
Our Warranty : 90 Days.
| Capacity | 24 PORT |
|---|---|
| Condition | Refurbished |
| Manufacturer | DELL |
